Chevrolet Pickup K1500 (1988-1999) engine controls system transmission system engine controls system Wiring diagram
This page shows the only wiring diagram for the component.engine controls system transmission system engine controls system, which is found in the car Chevrolet Pickup K1500 (1988-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine controls system transmission system engine controls system (1 of 1)
ACCY
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/WHT WIRE
BRAKE IND IN
BRAKE PRESSURE WARNING SWITCH (ON REAR OF EBCM CASTING)
BRN WIRE
BULB TEST
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ELECTRONIC BRAKE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
ENG-1 MINI FUSE
ENGINE CONTROLS SYSTEM (FUEL PUMP BALANCE RELAY)
ENGINE CONTROLS SYSTEM TRANSMISSION SYSTEM ENGINE CONTROLS SYSTEM
FUEL GAGE SENDER (IN FRONT FUEL TANK)
FUEL PUMP BALANCE MODULE (INSIDE LEFT SIDE OF FRAME RAIL)
FUEL PUMP/ SENDER
GAUGES FUSE 4
GRN WIRE
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK (LEFT END OF DASH)
IGN E MINI FUSE
IGN SW BRAKE IND BRAKE PSI PK BRAKE 33 33
IGNITION SWITCH
LOCK OFF
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
M/T A/T
PARK BRAKE WARNING SWITCH (ON PARKING BRAKE PEDAL BRACKET)
PNK PNK WIRE
PNK PPL WIRE
PNK WIRE
PPL
PPL/WHT WIRE
RADIO
RUN WIRE
SECONDARY FUEL GAGE SENDER (IN REAR FUEL TANK)
SINGLE FUEL TANK DUAL FUEL TANKS
TAN/WHT WIRE
TRANS FUSE 20
TWISTED PAIR
UNDERHOOD FUSE-RELAY CENTER (LEFT REAR OF ENGINE COMPT)
UNDERHOOD FUSE-RELAY CENTER (LEFT REAR OF ENGINE COMPT) DIODE 1
VEHICLE SPEED SENSOR (LEFT REAR OF TRANSMISSION OR TRANSFER CASE)
VEHICLE SPEED SENSOR (VSS) ADAPTER
VEHICLE SPEED SENSOR BUFFER (BEHIND RIGHT SIDE OF DASH)
WHT TAN/ WIRE
WHT WIRE
YEL/BLK WIRE
Go to component -> 6.5l (vin s), instrument cluster circuit (2 of 2) -> ENGINE CONTROLS SYSTEM TRANSMISSION SYSTEM ENGINE CONTROLS SYSTEM
