Chevrolet Pickup K1500 (1988-1999) body shock control sensor module Wiring diagram
This page shows the only wiring diagram for the component.body shock control sensor module, which is found in the car Chevrolet Pickup K1500 (1988-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram body shock control sensor module (1 of 1)
ASHTRAY LAMP
AUDIO ALARM MODULE
AUTOMATIC FRONT TRANSFER AUXILIARY CASE POWER SELECT OUTLET SWITCH
AUTOMATIC TURN/ TRANSFER HAZARD CASE FLASHER CONTROL MODULE
AUXILIARY COOLING FAN MOTOR
BLK WIRE
BLK/GRY WIRE
BODY SHOCK CONTROL SENSOR MODULE
BRAKE TRANS- MISSION SHIFT JAMB INTERLOCK IGNITION SWITCH SWITCH SWITCH
CONVENIENCE CENTER
DATA LINK CONNECTOR
DAYTIME RUNNING LAMPS MODULE
FRONT HEATER AND AUXILIARY A/C POWER CONTROL OUTLET SWITCH
FRONT WINDSHIELD WIPER/ WASHER PUMP MOTOR
GROUND STRAP
HORN SWITCH
HVAC CONTROL MODULE
INFLATABLE CARGO RESTRAINT LAMP I/P MODULE SWITCH ENABLE (PICKUP) SWITCH
KEY-IN WARNING BUZZER SWITCH (UPPER LEVEL)
LEFT BATTERY
LEFT FOG LAMP
LEFT FRONT PARK/ TURN LAMP
LEFT HIGH/ LOW BEAM HEADLAMP
LEFT HORN
LEFT LEFT HIGH LOW BEAM BEAM HEADLAMP HEADLAMP
PICKUP ONLY
POLICE PACKAGE
RADIO
REAR STEREO CONTROLLER
REAR WINDOW WASHER PUMP MOTOR
REAR WINDOW WIPER/ WASHER SWITCH (SUBURBAN/ UTILITY)
RIGHT FOG LAMP
RIGHT FRONT PARK/ TURN LAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT HIGH/ LOW BEAM HEADLAMP
RIGHT HORN
RIGHT LOW BEAM HEADLAMP
SPARE
SPOT LAMP
SPOT LAMP RELAY
TRANSFER CASE CONTROL MODULE
TRANSFER CASE SELECT SWITCH
UNCOATED
UNDER- HOOD LAMP
VEHICLE LOW COOLANT INTERFACE LEVEL UNIT INDICATOR (UPPER MODULE LEVEL) (DIESEL)
W/ DUAL HORNS
W/ QUAD HEADLAMPS
W/ QUAD HEADLAMPS/ SPORT PACKAGE
WINDSHIELD HEADLAMP WIPER AND PANEL MOTOR DIMMER MODULE SWITCH
Go to component -> Ground distribution circuit (1 of 4) -> BODY SHOCK CONTROL SENSOR MODULE
