Chevrolet Pickup K1500 (1988-1999) 6-way power seat circuit Wiring diagrams
This page contains all the electrical diagrams for the component. 6-way power seat circuit, in which he is found in the car Chevrolet Pickup K1500 (1988-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 6-way power seat circuit (1 of 3)
6-WAY POWER SEAT CIRCUIT
BLK WIRE
CONVENIENCE CENTER (UNDER LEFT SIDE OF DASH)
DK BLU WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK
LEFT POWER LUMBAR SUPPORT MOTOR
LEFT POWER SEAT LUMBAR SWITCH
NCA WIRE
ORG/ WIRE
POWER SEAT ADJUSTER SWITCH
PWR-ACCY CIRCUIT BREAKER
RIGHT POWER LUMBAR SUPPORT MOTOR
RIGHT POWER SEAT LUMBAR SWITCH
Go to component -> Lumbar circuit, bench seat -> 6-WAY POWER SEAT CIRCUIT
Wiring diagram 6-way power seat circuit (2 of 3)
6-WAY POWER SEAT CIRCUIT
BLK WIRE
CIG LTR FUSE 13
CONVENIENCE CENTER (UNDER LEFT SIDE OF I/P)
HOT AT ALL TIMES
I/P FUSE BLOCK (LOWER LEFT SIDE OF I/P)
LEFT POWER LUMBAR SUPPORT SWITCH
ORG/ WIRE
PNK LEFT POWER LUMBAR SUPPORT MOTOR WIRE
PNK WIRE
RIGHT POWER LUMBAR SUPPORT MOTOR
RIGHT POWER LUMBAR SUPPORT SWITCH
SUBURBAN, UTILITY ONLY
Go to component -> Lumbar circuit, bucket and split bench seat -> 6-WAY POWER SEAT CIRCUIT
Wiring diagram 6-way power seat circuit (3 of 3)
6-WAY POWER SEAT CIRCUIT
BLK WIRE
CIG LTR FUSE 13
CONVENIENCE CENTER (UNDER LEFT SIDE OF DASH)
DK BLU WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK
LEFT POWER LUMBAR SUPPORT MOTOR
LEFT POWER SEAT LUMBAR SWITCH
NCA WIRE
ORG/ WIRE
RIGHT POWER LUMBAR SUPPORT MOTOR
RIGHT POWER SEAT LUMBAR SWITCH
SUBURBAN, UTILITY ONLY
Go to component -> Lumbar circuit, bucket and split bench with heated seat -> 6-WAY POWER SEAT CIRCUIT
