Fog lamp circuit, sealed beam with drl for Chevrolet Pickup C3500 (1988-2000)

BLK WIRE BRN WIRE BULB CHECK FOG LTS ENABLE CONVENIENCE CENTER DAYTIME RUNNING LAMP INDICATOR INSTRUMENT CLUSTER DAYTIME RUNNING LAMPS MODULE (BEHIND LEFT SIDE OF I/P) DAYTIME RUNNING LAMPS RELAY (ENGINE COMPARTMENT FRONT PLENUM PANEL) DIODE DK BLU WIRE DK GRN/WHT WIRE FOG LAMP ON INDICATOR SOLID STATE SWITCH FOG LAMP RELAY FOG LAMP SWITCH GRN WIRE GRY WIRE HEAD PARK HEADLAMP DIMMER SWITCH HEADLIGHT SWITCH ASSEMBLY HI BEAM INDICATOR HI LO HOT AT ALL TIMES HOT AT ALL TIMES DRL-FOG FUSE 15 HOT IN RUN, BULB TEST OR START FUSE BLOCK GAUGES FUSE 4 ILLUM LAMP LAMP FEED HI BEAM FEED HI BEAM INDICATOR LEFT HEADLAMP ASSEMBLY HI LO LT GRN WIRE LT GRN/BLK WIRE OFF OFF HEAD ORG/ WIRE OUTPUT TO RELAY GROUND PARK PARK BRAKE WARNING SWITCH (AT PARK BRAKE, UNDER LEFT SIDE OF I/P) PICKUP EXT. CAB PNK IGNITION WIRE PNK WIRE PPL PPL LEFT FOG LAMP PPL RIGHT FOG LAMP RIGHT HEADLAMP ASSEMBLY HI LO SUBURBAN PICKUP UTILITY EXT. CAB CREW CAB SUBURBAN UTILITY CREW CAB TAN WIRE TAN/WHT WIRE WHT WIRE YEL WIRE
