Chevrolet Pickup C1500 (1988-1999) low glow coolant plug level relay sensor Wiring diagram
This page shows the only wiring diagram for the component.low glow coolant plug level relay sensor, which is found in the car Chevrolet Pickup C1500 (1988-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low glow coolant plug level relay sensor (1 of 1)
A/C COMPRESSOR CLUTCH
A/C LOW PRESSURE SWITCH
BLK WIRE
BLOWER MOTOR
BRAKE PRESSURE WARNING SWITCH
DIESEL
DK GRN WIRE
ELECTRONIC BRAKE CONTROL MODULE
FRONT AXLE ACTUATOR
FRONT MODE DOOR MOTOR
FRONT TEMPERATURE DOOR MOTOR
HIGH BLOWER MOTOR RELAY
LOW GLOW COOLANT PLUG LEVEL RELAY SENSOR
PARK/ NEUTRAL POSITION SWITCH
RECIRCULATION DOOR MOTOR
STOPLAMP STARTER RELAY RELAY
TRANSFER CASE RELAY
TRANSFER CASE RELAY BREAKOUT)
UNDER- HOOD LAMP
UNDER- HOOD REEL LAMP
UNDERHOOD FUSE- RELAY CENTER A/C COMPRESSOR CLUTCH RELAY
UNDERHOOD FUSE-RELAY CENTER
WATER-IN- FUEL FUEL HEATER SENSOR
Go to component -> Ground distribution circuit (5 of 5) -> LOW GLOW COOLANT PLUG LEVEL RELAY SENSOR
