Starting circuit for Chevrolet Metro I (1997-2001)

Starting circuit

Get access

A/T BATT FUSE BATTERY BLK RED/ WIRE BLK WIRE BLK/ YEL WIRE BLK/RED WIRE BLK/YEL WIRE BREAKOUT TO STARTER SOLENOID) CLUTCH PEDAL POSITION SWITCH (ABOVE CLUTCH PEDAL) ENGINE CONTROLS SYSTEM FUSE BOX (LEFT SIDE OF ENGINE COMPT, BEHIND BATTERY) IG FUSE IGNITION SWITCH JUNCTION BLOCK (LEFT SIDE OF DASH) LOCK M/T RED/YEL WIRE STARTER STARTER SOLENOID TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE) WHT WIRE WHT/GRN WIRE
