Charging circuit for Chevrolet Metro I (1997-2001)
Charging circuit
1998-99
BATT FUSE
BATTERY
BLK (OR WHT/GRN) WIRE
BLK WIRE
BLK/WHT WIRE
BULKHEAD GROMMET)
CHARGE INDICATOR
DAYTIME RUNNING LAMPS CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
FUSE BOX (LEFT SIDE OF ENGINE COMPT, BEHIND BATTERY)
GENERATOR
IG FUSE
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER ASSEMBLY
JUNCTION BLOCK (LEFT SIDE OF DASH)
JUNCTION BLOCK (LEFT SIDE OF DASH) IG-COIL FUSE
LOCK
RUN WIRE
STARTER SOLENOID
WHT GRN/ WIRE
WHT WIRE
WHT/RED WIRE
