Cooling fan circuit for Chevrolet Metro I (1997-2001)

Cooling fan circuit

Get access

A/C 1 RELAY A/C 2 RELAY A/C COMPRESSOR CONTROL MODULE (BELOW RIGHT SIDE OF DASH, ON EVAPORATOR CASE) A/C CONDENSER FAN MOTOR A/C FUSE BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE ENGINE COOLING FAN RELAY FUSE BOX HOT AT ALL TIMES HOT IN ON JUNCTION BLOCK HTR FUSE HOT IN ON OR START IG FUSE LT GRN WIRE PNK A/C RELAY WIRE PNK WIRE POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH, NEAR GLOVE BOX) RADIATOR FAN MOTOR RDTR FUSE RED/BLU WIRE RED/WHT WIRE RELAY BOX RELAY CTRL
