Chevrolet Metro I (1997-2001) sensing and diagnostic module Wiring diagram
This page shows the only wiring diagram for the component.sensing and diagnostic module, which is found in the car Chevrolet Metro I (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sensing and diagnostic module (1 of 1)
4 DOOR
AT LEFT REAR OF TRUNK)
AT RIGHT REAR OF TRUNK)
BLK WIRE
CENTER HIGH MOUNTED STOP LAMP
COMBINATION LAMP CONN BREAKOUT)
FROM BREAKOUT TO LUGGAGE COMPARTMENT HARNESS)
FROM CENTER CONSOLE BRANCH BREAKOUT)
FUEL SENDER ASSEMBLY
GRN WIRE
GROMMET AT RIGHT REAR OF TRUNK)
GRY WIRE
INFLATABLE RESTRAINT FORWARD DISCRIMINATING SENSOR
LEFT REAR COMBINATION LAMP
LEFT REAR COMBINATION LAMP CONNECTOR BREAKOUT)
LICENSE PLATE LAMP
REAR DEFOGGER
REAR OF TRUNK)
RED WIRE
RIGHT REAR COMBINATION LAMP
SEAT BELT SWITCH
SENSING AND DIAGNOSTIC MODULE
SHIFT LOCK SOLENOID
SUPPLEMENTAL INFLATABLE RESTRAINT DATA LINK CONNECTOR
WHT WIRE
Go to component -> Ground distribution circuit (3 of 3) -> SENSING AND DIAGNOSTIC MODULE
