Chevrolet Metro I (1997-2001) from dash cluster breakout) Wiring diagram
This page shows the only wiring diagram for the component.from dash cluster breakout), which is found in the car Chevrolet Metro I (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram from dash cluster breakout) (1 of 1)
A/C CONDENSER FAN
AUDIO ALARM MODULE
BLK WIRE
BLOWER MOTOR
BLU WIRE
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP
CIGAR LIGHTER
CIGAR LIGHTER CONNECTOR BREAKOUT)
COMBINATION SWITCH
DATA LINK CONNECTOR ON-BOARD DIAGNOSTIC II
DIMMER SWITCH
DUAL PRESSURE SWITCH
EARLY FUEL EVAPORATION HEATER
FROM
FROM BULKHEAD GROMMET, CENTER OF FIREWALL)
FROM DASH CLUSTER BREAKOUT)
FROM DLC-OBD II BREAKOUT)
FROM I/P CLUSTER
FROM RADIO CONN BREAKOUT)
FRONT WIPER/ WASHER SWITCH
GRN WIRE
IGNITION CONTROL MODULE
IGNITION SWITCH
ILLUMINATION CONTROLLER
INSTRUMENT PANEL CLUSTER ASSEMBLY
JUNCTION BLOCK
LEFT POWER DOOR LOCK SWITCH
LIGHT SWITCH
NOISE SUPPRESSOR FILTER
RADIO
REAR DEFOGGER SWITCH
REAR WIPER MOTOR
RED WIRE
RED/BLK WIRE
RIGHT FRONT PARK/TURN LAMP
RIGHT PARKING LAMP
RIGHT POWER DOOR LOCK SWITCH POWER DOOR LOCK CONTROL MODULE
TURN RELAY
VIN 6 VIN 9
WHT WIRE
Go to component -> Ground distribution circuit (2 of 3) -> FROM DASH CLUSTER BREAKOUT)
