Trunk release circuit for Chevrolet Malibu VIII facelift (2013-2016)
Trunk release circuit
BLK WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
FUSE
GRN WIRE
GROUND
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (LEFT SIDE OF DASH)
INSTRUMENT CLUSTER
LIFT GATE AJAR SW SIG 1
LIFT GLASS/TRUNK MTR RELEASE CTRL
LO SPD GMLAN SERIAL DATA
LO SPD GMLAN SERIAL DATA B+ 22 1
LOGIC
REAR CLOSURE HNDL SW OPEN SIG
REAR COMPARTMENT LID LATCH (BOTTOM OF REAR COMPT LID)
REAR COMPARTMENT LID UNLATCH RELAY
REAR COMPARTMENT LID UNLATCH SWITCH (TOP OF REAR COMPT LID)
RED/WHT WIRE
VIO WIRE
YEL/BLU WIRE
