Defoggers circuit for Chevrolet Malibu VIII facelift (2013-2016)
Defoggers circuit
BATTERY FUSE BLOCK (ON BATTERY)
BLK WIRE
BRN WIRE
BRN/VIO WIRE
BRN/YEL WIRE
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER OUTSIDE REARVIEW MIRROR GLASS
FUSE 5
GRN/YEL WIRE
HOT AT ALL TIMES
HVAC CONTROL MODULE (CENTER OF DASH)
HVAC CONTROLS
LEFT REAR WINDOW DEFOGGER NOISE FILTER (AT LEFT "C" PILLAR)
LOGIC
MIRR DEFOG (HYBRID) HTD MIR (EXCEPT HYBRID) FUSE
NCA WIRE
NETWORK 9
PASSENGER OUTSIDE REARVIEW MIRROR
PASSENGER OUTSIDE REARVIEW MIRROR GLASS
REAR DEFOG RLY CTRL
REAR DEFOGGER GRID
REAR DEFOGGER IND
REAR DEFOGGER RELAY
REAR DEFOGGER SWITCH
RED WIRE
RIGHT REAR WINDOW DEFOGGER NOISE FILTER (AT RIGHT "C" PILLAR)
RR WDW DEFOG (HYBRID) RR DEFOG (EXCEPT HYBRID) FUSE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
YEL WIRE
