Chevrolet Malibu VIII facelift (2013-2016) hi spd gmlan serial data + hi spd gmlan serial data - 24 23 Wiring diagram
This page shows the only wiring diagram for the component.hi spd gmlan serial data + hi spd gmlan serial data - 24 23, which is found in the car Chevrolet Malibu VIII facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hi spd gmlan serial data + hi spd gmlan serial data - 24 23 (1 of 1)
185 893 419 WIPER/WASHER SYSTEM
ABS IND.
AIR BAG IND
AMBIENT AIR TEMPERATURE SENSOR
AMBIENT AIR TEMPERATURE SENSOR (LEFT SIDE OF LOWER GRILLE)
BATTERY POS VOLT
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BODY CONTROL MODULE (BEHIND LEFT END OF DASH)
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
BRAKE WARNING IND LAMP
BRN WIRE
BRN/WHT WIRE
BUS 2
CHARGE IND
COIL
COMPUTER DATA LINES SYSTEM
CONTROL
CRUISE IND
DIM CTRL LED CTRL
DIM CTRL LED CTRL WASHER FLUID IND CTRL DRV CENTER MENU SW SIG
DPF IND
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE GAUGE
ENGINE IND CTRL
FRONT FOG LAMP IND
FUEL GAUGE
FUEL IND
FUSE 21
GRN WIRE
GRN/BLU WIRE
GROUND
GROUND DISTRIBUTION SYSTEM
GROUND DISTRIBUTION SYSTEM 3535 3885 NAVIGATION SYSTEM
GRY WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HI SPD GMLAN SERIAL DATA + HI SPD GMLAN SERIAL DATA -
HI SPD GMLAN SERIAL DATA + HI SPD GMLAN SERIAL DATA - 24 23
HIGH BEAM IND
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN 1 VOLT
IGN 1 VOLT BATTERY POS
ILLUMINATION IND
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL FUSE BLOCK (LEFT SIDE OF DASH)
LANE DEPARTURE WARNING (LDW) LIGHT
LEFT TURN IND
LIFT GATE AJAR SW SIG
LIGHTS ON IND
LO SPD GMLAN SER DATA DRV INFORMATION SW SIG DRV LO REF
LO SPD GMLAN SER DATA DRV INFORMATION SW SIG DRV LO REF SENS LO REF SENS SIG
LOGIC
LOW TIRE PRESSURE IND
MALFUNCTION IND LAMP (MIL)
MENU
MIL IGN FUSE
NAVIGATION SYSTEM
NETWORK
OIL LEVEL IND LAMP
PARK BRAKE IND
PARK BRAKE SERVICE IND
PARK BRAKE SWITCH
PARK BRAKE SWITCH (MOUNTED TO SHIFT LEVER BEZEL)
PARK BRK SW SIG
PARK IND
PARK LIGHT INDICATOR
POWER DISTRIBUTION SYSTEM
RAP RELAY
RAP RELAY COIL CTRL
RED/GRY WIRE
RIGHT TURN IND
SEAT BELT IND LAMP
SECURITY IND
SENS LO REF
SENS SIG
SET-
SPEEDOMETER
TACHOMETER
TRACTION CONTROL IND
TRACTION OFF IND
TRANSMISSION SHIFT LEVER POSITION INDICATOR
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
VDC IND
VIO WIRE
VIO/GRY WIRE
VOLT
W/ FRONT GRILL ACTIVE SHUTTERS
WAIT TO START IND
WAIT-TO START IND LOGIC
WASHER FLUID IND CTRL DRV CENTER MENU SW SIG
WATER IN FUEL IND
WHT WIRE
WHT/GRN WIRE
WIPER/WASHER SYSTEM
Go to component -> Instrument cluster circuit (1 of 2) -> HI SPD GMLAN SERIAL DATA + HI SPD GMLAN SERIAL DATA - 24 23
