Chevrolet Malibu VIII facelift (2013-2016) computer computer data lines data lines system system Wiring diagrams
This page contains all the electrical diagrams for the component. computer computer data lines data lines system system, in which he is found in the car Chevrolet Malibu VIII facelift (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram computer computer data lines data lines system system (1 of 2)
2.0L VIN X
2.5L VIN L
ACCELERATOR PEDAL POSITION SENSOR
BATT POS VOLT
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER COMPUTER DATA LINES DATA LINES SYSTEM SYSTEM
COMPUTER DATA LINES SYSTEM
DK BLU/BRN WIRE
FROM ENGINE CONTROLS IGNITION RELAY (DIAGRAM 3 OF 6)
FUEL LEVEL SENSOR
FUEL PUMP
FUEL PUMP DRIVER CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT)
FUEL PUMP DRIVER CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT)
FUEL PUMP, LEVEL SENSOR ASSEMBLY
FUEL PUMP, LEVEL SENSOR ASSEMBLY (TOP OF FUEL TANK)
GMLAN SER DATA
GRN/WHT WIRE
GRY WIRE
GRY/DK BLU WIRE
HOT AT ALL TIMES
IGNITION 1 VOLT
LOW REF
LT GRN/DK BLU WIRE
NCA WIRE
OUT SIG
RED/BRN WIRE
RED/VIO WIRE
SAIR SOL FUSE
SEC AIR PUMP FUSE
SECONDARY AIR INJECTION PUMP (2.5L: RIGHT SIDE OF ENGINE)
SECONDARY AIR INJECTION PUMP RELAY (CALIFORNIA EMISSION SYSTEM)
SECONDARY AIR INJECTION SOLENOID
SHIELD EXTENSION
SPLY VOLT
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
VALVE RELAY (CALIFORNIA EMISSION SYSTEM)
VIO/BLK WIRE
VIO/BLU WIRE
VIO/DK BLU WIRE
VIO/GRN WIRE
VIO/YEL WIRE
WAKEUP SERIAL DATA
WHT WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 2.0l vin x (2 of 6) -> COMPUTER COMPUTER DATA LINES DATA LINES SYSTEM SYSTEM
