Chevrolet Malibu VIII facelift (2013-2016) can bus high 2 serial data can bus low 2 serial data Wiring diagram
This page shows the only wiring diagram for the component.can bus high 2 serial data can bus low 2 serial data, which is found in the car Chevrolet Malibu VIII facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram can bus high 2 serial data can bus low 2 serial data (1 of 1)
BATT POS VOLT
BATTERY ENERGY CONTROL MODULE
BATTERY FUSE BLOCK (ON BATTERY)
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/VIO WIRE
BPIM FUSE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CAN BUS HIGH 2 SERIAL DATA CAN BUS LOW 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
COOLANT PUMP RLY COIL CTRL
COOLANT TEMP SENS SIG
ENGINE CONTROL IGNITION RELAY
FAN SPD SENS SUPPLY VOLT
FAN SPD SIG (1)
FAN SPD SIG (2)
FUSE
GRN WIRE
GRN/VIO WIRE
GROUND
GRY WIRE
GRY/YEL WIRE
HI SPD HIGH 2 SERIAL DATA (+)
HI SPD LOW 2 SERIAL DATA (-)
HOT AT ALL TIMES
HYBRID/EV BATTERY PACK (BEHIND REAR SEATS IN LUGGAGE COMPT)
HYBRID/EV BATTERY PACK COOLING FAN (UNDER RIGHT REAR SHELF)
HYBRID/EV BATTERY SECTION 1
HYBRID/EV BATTERY SECTION 2
HYBRID/EV BATTERY TEMPERATURE SENSOR 1
HYBRID/EV BATTERY TEMPERATURE SENSOR 2
HYBRID/EV BATTERY TEMPERATURE SENSOR 4
HYBRID/EV BATTERY TEMPERATURE SENSOR 5
HYBRID/EV BATTERY TEMPERATURE SENSOR 6
HYBRID/EV POWERTRAIN CONTROL MODULE STARTER/GENERATOR CONTROL MODULE
LOGIC
MGU COOL PMP FUSE
ORG/ WIRE
ORG/GRY WIRE
PNK/BLK WIRE
RED WIRE
RED/YEL WIRE
SENS LOW REF
STARTER/ GENERATOR COOLANT PUMP (LOWER LEFT REAR OF ENGINE)
STARTER/ GENERATOR COOLANT PUMP RELAY
STARTER/ GENERATOR COOLANT TEMPERATURE SENSOR
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
VIO WIRE
VIO/YEL WIRE
W/ START/STOP SYSTEM
W/O START/STOP SYSTEM
WAKEUP SER DATA
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
