Chevrolet Malibu VIII facelift (2013-2016) brake position sensor low reference Wiring diagrams
This page contains all the electrical diagrams for the component. brake position sensor low reference, in which he is found in the car Chevrolet Malibu VIII facelift (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram brake position sensor low reference (1 of 2)
2.0L 2.5L
2.0L 2.5L, 2.4L
ACCESSORY VOLTAGE
AUTOMATIC TRANSMISSION ASSEMBLY
BATTERY POSITIVE VOLT
BATTERY POSITIVE VOLTAGE
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BODY CONTROL MODULE (BEHIND LEFT END OF DASH)
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
BRAKE APPLY SENSOR LOW REFERENCE
BRAKE APPLY SENSOR SIGNAL
BRAKE APPLY SENSOR SUPPLY VOLTAGE
BRAKE PEDAL POSITION SENSOR
BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY)
BRAKE POSITION SENSOR 5 VOLT REFERENCE
BRAKE POSITION SENSOR LOW REFERENCE
BRAKE POSITION SENSOR SIGNAL
BRN WIRE
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
DK BLU/WHT WIRE
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (TOP OF TRANSMISSION)
EXCEPT HYBRID
FUSE
FUSE 22
FUSE 24
FUSE 8
GRN WIRE
GROUND
GRY WIRE
HIGH SPEED GMLAN SERIAL DATA (+)
HOT AT ALL TIMES
HYBRID/EV BATTERY PACK (BEHIND REAR SEATS IN LUGGAGE COMPT)
HYBRID/EV POWERTRAIN CONTROL MODULE
IGNITION SWITCH
IGNITION SWITCH (W/O KEYLESS ENGINE START SWITCH)
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL FUSE BLOCK (LEFT SIDE OF DASH)
KEY CAPTURE SOLENOID ACTUATOR
KEY CAPTURE SOLENOID ACTUATOR (IGNITION LOCK CYLINDER HOUSING)
KEY CAPTURE/COLUMN LOCK SHIFT POSITION SIGNAL
KEY-IN SWITCH
LT GRN WIRE
OFF
OFF/RUN/CRANK VOLTAGE
PARK POSITION SWITCH
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/WHT WIRE
RUN WIRE
SHIFT LEVER TRANSMISSION
STARTER/GENERATOR CONTROL MODULE
SWITCH
SYSTEM
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SWITCH
TRANSMISSION P/N SIG
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT MANUAL SWITCH
VIO WIRE
VIO/YEL WIRE
W/ KEYLESS ENGINE
W/ KEYLESS ENGINE START SWITCH
W/O KEYLESS ENGINE
W/O KEYLESS ENGINE START SWITCH
WHT WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/LT GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Ignition lock solenoid circuit -> BRAKE POSITION SENSOR LOW REFERENCE
Wiring diagram brake position sensor low reference (2 of 2)
2.0L 2.5L
2.0L 2.5L, 2.4L
AUTOMATIC TRANSMISSION ASSEMBLY
BATTERY POSITIVE VOLT
BATTERY POSITIVE VOLTAGE
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BODY CONTROL MODULE (BEHIND LEFT END OF DASH)
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
BRAKE APPLY SENSOR LOW REFERENCE
BRAKE APPLY SENSOR SIGNAL
BRAKE APPLY SENSOR SUPPLY VOLTAGE
BRAKE PEDAL POSITION SENSOR
BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY)
BRAKE POSITION SENSOR 5 VOLT REFERENCE
BRAKE POSITION SENSOR LOW REFERENCE
BRAKE POSITION SENSOR SIGNAL
BRN WIRE
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (TOP OF TRANSMISSION)
EXCEPT HYBRID
FUSE 24
FUSE 3
FUSE 8
GRN WIRE
GROUND
GRY WIRE
GRY/VIO WIRE
HIGH SPEED GMLAN SERIAL DATA (+)
HOT AT ALL TIMES
HYBRID/EV POWERTRAIN CONTROL MODULE
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL FUSE BLOCK (LEFT SIDE OF DASH)
LT GRN WIRE
ORG/WHT WIRE
PARK LOCK SOLENOID CONTROL
POWER DISTRIBUTION SYSTEM
PRK LCK SOL CTRL
RAD RLY COIL CTRL
RAP RELAY COIL CONTROL
RED WIRE
RED/BRN WIRE
RED/WHT WIRE
SYSTEM
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SWITCH
TRANSMISSION MANUAL SHIFT SWITCH
TRANSMISSION P/N SIG
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
VIO WIRE
VIO/BLK WIRE
WHT WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/LT GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> BRAKE POSITION SENSOR LOW REFERENCE
