Wiring diagram body control module (behind left (1 of 2)
25 24 SERIAL DATA (-) SERIAL DATA (+)
2501 2500 COMPUTER DATA LINES SYSTEM
AMBIENT LIGHT SENSOR (WINDSHIELD SIDE)
BACKUP LAMP SUPPLY VOLT
BACKUP SPLY
BCM 6 FUSE
BDY RC IGN FUSE
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BODY CONTROL MODULE (BEHIND LEFT
COMPUTER DATA LINES SYSTEM
DISPLAY
DRIVER INFORMATION CENTER DISPLAY
EMERGENCY IND
EMERGENCY SWITCH
GRN WIRE
GRN/WHT WIRE
GROUND
HEADLIGHT SENSOR (MIRROR SIDE)
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN 1 VOLTAGE
INSIDE REAR VIEW MIRROR
INSIDE REARVIEW MIRROR
KEYPAD
KEYPAD GREEN LED
KEYPAD GREEN LED IND
KEYPAD RED LED IND WIRE
KEYPAD RED LED WIRE
KEYPAD SIGNAL
KEYPAD SPLY VOLT
LOGIC
NCA WIRE
OF REAR SHELF)
ONSTAR IND
ONSTAR SWITCH
PHONE IND
PHONE SWITCH
RED LED IND WIRE
RED WIRE
RED/WHT WIRE
SERIAL DATA
SIDE OF DASH)
TELEMATICS BUTTON ASSEMBLY
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE (CENTER OF REAR SHELF)
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
VIO WIRE
VIO/BLK WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electrochromic mirror circuit -> BODY CONTROL MODULE (BEHIND LEFT
Wiring diagram body control module (behind left (2 of 2)
2.0L 2.5L
AUTOMATIC TRANSMISSION ASSEMBLY
BATT POS VOLT
BATT RVC FUSE
BATTERY
BATTERY FUSE BLOCK (ON BATTERY) FUSE 5
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BEHIND LEFT
BRN WIRE
CHARGING CIRCUIT
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
ECM IGN FUSE
ENGINE COMPT)
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF
FUSE 22
FUSE 6
GRN WIRE
GRY WIRE
HIGH SPEED GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN KEY RESISTOR SIG
IGNITION SWITCH
INSTRUMENT CLUSTER DRIVER INFORMATION CENTER DISPLAY
LOGIC LOW SPEED GMLAN SERIAL DATA
OFF
OFF/RUN/CRANK VOLT
RED WIRE
RED/YEL WIRE
RUN WIRE
RUN/CRANK IGN 1 VOLT
SIDE OF DASH)
SIG GND
STARTER ENABLE RELAY CTRL
STARTER FUSE
STARTER MOTOR
STARTER RELAY
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SWITCH
TRANSMISSION PARK/ NEUTRAL SIG 1
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
WHT/GRY WIRE
YEL WIRE
Go to component -> Starting circuit, except hybrid without stop/start system -> BODY CONTROL MODULE (BEHIND LEFT
