Chevrolet Malibu VIII facelift (2013-2016) auxiliary info audio display input module Wiring diagram
This page shows the only wiring diagram for the component.auxiliary info audio display input module, which is found in the car Chevrolet Malibu VIII facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auxiliary info audio display input module (1 of 1)
2.0L
2.5L
ACTIVE GRILLE AIR SHUTTER ACTUATOR
APM FUSE
AUXILIARY AUDIO INPUT
AUXILIARY INFO AUDIO DISPLAY INPUT MODULE
BATTERY ENERGY CONTROL MODULE
BDY RC IGN FUSE
BLK WIRE
BLK/ VIO WIRE
BLU WIRE
BODY CONTROL MODULE
BPIM IGN PT RC IGN FUSE
COLLISION ALERT INDICATORS
COLLISION ALERT INDICATORS (IF EQUIPPED)
DATA LINK CONNECTOR
DBIM FUSE
DK BLU WIRE
ECM IGN FUSE
ENGINE CONTROL MODULE
FROM BATTERY FUSE BLOCK (DIAGRAM 1 OF 6)
FROM BODY CONTROL MODULE (DIAGRAM 6 OF 6)
FROM CPS FUSE (DIAGRAM 1 OF 6)
FUSE
FUSE 14
FUSE 15
FUSE 17
FUSE 19
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 26
FUSE 73
FUSE FUSE
GRN/VIO WIRE
HVAC CONTROL MODULE
HVAC CONTROLS
HVAC RADIO CONTROLS CONTROLS
HYBRID/EV BATTERY PACK
HYBRID/EV BATTERY PACK (2.4L)
HYBRID/EV POWERTRAIN CONTROL MODULE
IGNITION MAIN RELAY
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INFO DISPLAY MODULE
INSIDE REAR VIEW MIRROR
INSIDE REARVIEW MIRROR (IF EQUIPPED)
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER 2.4L EXCEPT 2.4L 2.5L EXCEPT 2.5L
INSTRUMENT PANEL FUSE BLOCK
IP RC IGN FUSE
MIL IGN FUSE
PASSENGER AIR BAG DISABLED INDICATOR
PASSENGER CHASSIS CONTROL AIR BAG DISABLED MODULE INDICATOR (2.4L)
PASSENGER INSTRUMENT PRESENCE CLUSTER MODULE
PASSENGER PRESENCE MODULE
PT RC IGN FUSE
RADIO CONTROLS
REAR DEFOGGER RELAY
REAR VIEW CAMERA
REARVIEW CAMERA (IF EQUIPPED)
RED WIRE
RED/ WHT WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
SDM IGN FUSE
SDM IGN MIL IGN FUSE
STARTER/ GENERATOR CONTROL MODULE
STARTER/GENERATOR CONTROL MODULE
TO BATTERY FUSE BLOCK (DIAGRAM 1 OF 6)
TO BODY CONTROL MODULE (DIAGRAM 6 OF 6)
TO FUSE 16 (DIAGRAM 4 OF 6)
TO IGNITION DATA LINK SWITCH CONNECTOR (DIAGRAM 6 OF 6)
TO IGNITION SWITCH (DIAGRAM 6 OF 6)
TO STARTER FUSE (DIAGRAM 3 OF 6)
TO TC FSC IGN FUSE (DIAGRAM 3 OF 6)
TO TC FSCM IGN FUSE (DIAGRAM 3 OF 6)
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
VENT SEAT FUSE
VIO WIRE
VIO/BLK WIRE
VIO/GRN (OR VIO/LT GRN) WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
W/ NAVIGATION
W/ REAR VIEW CAMERA
W/O NAVIGATION
WHT RED/ WIRE
WHT WIRE
WINDSHIELD WASHER PUMP RELAY
Go to component -> Power distribution circuit (2 of 6) -> AUXILIARY INFO AUDIO DISPLAY INPUT MODULE
