Chevrolet Malibu VIII facelift (2013-2016) 1 1 rr side impact sir inflator ctrl rr side impact sir inflator sply volt ppl Wiring diagram

1 1 RR SIDE IMPACT SIR INFLATOR CTRL RR SIDE IMPACT SIR INFLATOR SPLY VOLT PPL 3-4, 7-8, 9-10, 11-12, 13-14, 15-16, 17-18, 37-38, 39-40, 53-54) BLK WIRE BLK/ORG WIRE BLU/ORG WIRE BRN WIRE BRN/GRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE DRIVER SEAT BELT ANCHOR PRETENSIONER DRIVER SEAT BELT BUCKLE DRIVER SEAT BELT SWITCH DRIVER SEAT SIDE AIR BAG DRV SEAT BELT PRETENSIONER HIGH CTRL DRV SEAT BELT PRETENSIONER LOW CTRL DRV SEAT BELT SWITCH LOW REF DRV SEAT BELT SWITCH SIG DRV SEAT POSITION SWITCH SIG DRV SIDE IMPACT MODULE HIGH CTRL DRV SIDE IMPACT MODULE LOW CTRL GRN/ORG WIRE INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) LEFT MIDDLE SIDE IMPACT SENSING MOD LOW REF LEFT MIDDLE SIDE IMPACT SENSING MOD SIG LEFT REAR SEAT SIDE AIR BAG LEFT REAR SEAT SIDE AIR BAG (IF EQUIPPED) (LEFT SIDE OF REAR SEAT BACK) LEVER ON FLOOR) LF DISCRIMINATING SNSR LOW REF LF DISCRIMINATING SNSR SIG LF HEAD CURTAIN MODULE HIGH CTRL LF HEAD CURTAIN MODULE LOW CTRL LF SEAT BELT PRETENSIONER STAGE 2 HIGH CTRL LF SEAT BELT PRETENSIONER STAGE 2 LOW CTRL LF SIDE IMPACT MODULE HIGH CTRL LF SIDE IMPACT MODULE LOW CTRL LR SIDE IMPACT SIR INFLATOR CTRL LR SIDE IMPACT SIR INFLATOR SPLY VOLT NCA WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE ORG/TAN WIRE ORG/VIO WIRE ORG/YEL WIRE PASS SEAT BELT BUCKLE PRETENSIONER HIGH CTRL PASS SEAT BELT BUCKLE PRETENSIONER LOW CTRL PASS SEAT BELT PRETENSIONER HIGH CTRL PASS SEAT BELT PRETENSIONER LOW CTRL PASS SEAT BELT SWITCH LOW REF PASS SEAT BELT SWITCH SIG PASS SEAT POSITION SWITCH SIG PASSENGER SEAT BELT ANCHOR PRETENSIONER PASSENGER SEAT BELT BUCKLE PASSENGER SEAT BELT SWITCH PASSENGER SEAT BELT SWITCH PASSENGER SEAT BELT BUCKLE PIN SHORTING BARS ENGAGED WHEN MODULE CONNECT IS DISCONNECTED FROM HARNESS: PPL RF DISCRIMINATING SNSR LOW REF RF DISCRIMINATING SNSR SIG RF HEAD CURTAIN MOD HIGH CTRL RF HEAD CURTAIN MOD LOW CTRL RF SEAT BELT PRETENSIONER STAGE 2 HIGH CTRL RF SEAT BELT PRETENSIONER STAGE 2 LOW CTRL RF SIDE IMPACT MODULE HIGH CTRL RF SIDE IMPACT MODULE LOW CTRL RIGHT MIDDLE SIDE IMPACT SENSING MOD LOW REF RIGHT MIDDLE SIDE IMPACT SENSING MOD SIG RIGHT MIDDLE SIDE IMPACT SENSOR (BASE OF RIGHT "B" PILLAR) RIGHT REAR SEAT SIDE AIR BAG RIGHT REAR SEAT SIDE AIR BAG (IF EQUIPPED) (RIGHT SIDE OF REAR SEAT BACK) RIGHT ROOF RAIL AIR BAG RIGHT ROOF RAIL AIR BAG (ABOVE RIGHT DOOR OPENINGS) RR SIDE IMPACT SIR INFLATOR CTRL RR SIDE IMPACT SIR INFLATOR SPLY VOLT SHORTING BAR VIO WIRE VIO/ORG WIRE WHT/ORG WIRE WHT/YEL WIRE YEL/ORG WIRE
