Car Wiring Diagrams for Starting circuit for Chevrolet Malibu VIII (2011-2014)

2.4L (VIN B) 2.4L (VIN B) 3.6L 3.6L 3.6L 2.4L (VIN B) AUTOMATIC TRANSMISSION AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS) BATTERY BLK WIRE COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT) FUSIBLE LINK 3 BU STARTER MOTOR GENERATOR GRY (OR BLK) WIRE HIGH SPEED GMLAN SERIAL DATA BUS + HOT AT ALL TIMES IGN LK CTRL SIG IGN SENSOR FUSE IGNITION 1 IGNITION SWITCH KEY-IN IGNITION SWITCH LOGIC OFF ORG/ WIRE ORG/BLK WIRE PNK WIRE PPL PPL/WHT WIRE RED WIRE RED/WHT WIRE RELAY 31 RUN WIRE STARTER RLY COIL CTRL STRTR FUSE 26 TAN WIRE TAN/BLK WIRE TRANSMISSION CONTROL MODULE (TCM) WHT (OR BLU) WIRE WHT WIRE WHT/BLK WIRE
