Video system circuit for Chevrolet Malibu VIII (2011-2014)
Video system circuit
2 1 FM ANT FM ANT
3 2 1 IGN
6 5 4 3 2 1 IGN VOLT GND L AUDIO (+) R AUDIO (+) VIDEO SIG (+) VIDEO SIG (-)
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE)
CLOCK SIG L AUDIO (+) R AUDIO (+) VIDEO SIG (+) VIDEO SIG (-)
DIGITAL VIDEO DISC (DVD) CONTROL MODULE
DIGITAL VIDEO DISC (DVD) CONTROL MODULE FUSE HOLDER
DRIVER SEAT HEADREST DIGITAL VIDEO DISC (DVD) DISPLAY
FM ANTENNA
HOT W/ ACCESSORY RELAY ENERGIZED
PASSENGER SEAT HEADREST DIGITAL VIDEO DISC (DVD) DISPLAY
RED WIRE
ROOF/HEAT SEAT FUSE
WHT WIRE
YEL WIRE
