Defoggers circuit for Chevrolet Malibu VIII (2011-2014)
Defoggers circuit
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE)
COMPUTER DATA LINES SYSTEM
DEFOG IND
DEFOG SWITCH
DK GRN WIRE
DRIVER OUTSIDE REARVIEW MIRROR (IF EQUIPPED)
HOT AT ALL TIMES
HTD MIR FUSE 24
HVAC CONTROL MODULE (AUTOMATIC A/C) (CENTER OF DASH)
HVAC CONTROL MODULE (MANUAL A/C) (CENTER OF DASH)
LEFT "C" PILLAR)
LOGIC
LOGIC RR DEFOG SW SIG
LOW SPD GMLAN SER DATA
LOW SPEED GMLAN SER DATA
LT BLU WIRE
NCA WIRE
PASSENGER OUTSIDE REARVIEW MIRROR (IF EQUIPPED)
PPL
R/WDO DEFOG RELAY 26
RBEC 1 FUSE 22
REAR FUSE BLOCK (LEFT SIDE OF TRUNK)
REAR WINDOW DEFOGGER GRID
RED/BLK WIRE
RR DEFOG FUSE 23
RR DEFOG RLY CTRL
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
