Chevrolet Malibu VIII (2011-2014) app sens 1 sig press sens sig app sens 2 sig Wiring diagram
This page shows the only wiring diagram for the component.app sens 1 sig press sens sig app sens 2 sig, which is found in the car Chevrolet Malibu VIII (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram app sens 1 sig press sens sig app sens 2 sig (1 of 1)
459 473 1310 AIR CONDITIONING SYSTEM COOLING FANS SYSTEM
5-VOLT REF 1 5-VOLT REF 2 5-VOLT REF 2 LOW REF LOW REF
ACC VOLT
ACC VOLT IGN 1 VOLT BATT POS VOLT PNK WIRE
ACCELERATOR PEDAL POSITION (APP) SENSOR (LEFT SIDE OF DASH)
APP SENS 1 SIG PRESS SENS SIG APP SENS 2 SIG
BLK WIRE
BLK/WHT WIRE
BRN WHT/BLK WIRE
BRN WIRE
BRN/WHT WIRE
CLUTCH RLY CTRL FAN RLY CTRL VENT SOL CTRL
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY MALFUNC- TION INDICATOR LAMP
ECM FUSE
ECM IGN FUSE 16
ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT)
FUEL TANK PRESSURE (FTP) SENSOR (INTEGRAL TO FUEL PUMP, SENDER ASSEMBLY)
GMLAN DATA
GRY WIRE
HOT AT ALL TIMES
IGN 1 VOLT
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER (IPC) LOGIC
LOGIC
LOW REF
LT BLU WIRE
MAF FUSE 5
MAIN RLY CTRL
MIL CTRL
MIL CTRL F PMP RLY CTRL
OFF
ORG/BLK WIRE
PNK WIRE
POWER DISTRIBUTION EXTERIOR LIGHTS SYSTEM SYSTEM
PPL
PPL FUEL LVL SENS
PPL/WHT WIRE
RED/WHT WIRE
RLY COIL CTRL
RUN WIRE
RUN/ CRANK RELAY 32
STARTER RLY CTRL
STARTING/CHARGING SYSTEM
STOP LMP SPLY
TAN WIRE
TAN/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.6l vin 7 (1 of 6) -> APP SENS 1 SIG PRESS SENS SIG APP SENS 2 SIG
