Trunk/tailgate release circuit for Chevrolet Malibu VII (2008-2012)
Trunk/tailgate release circuit
37 38 GMLAN SERIAL DATA GMLAN SERIAL DATA
7 8 GMLAN SERIAL DATA GMLAN SERIAL DATA
AJAR SWITCH
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE)
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DOOR LOCKS SYSTEM
DRIVER INFORMATION CENTER (DIC)
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LEFT "C" PILLAR)
LOGIC
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
REAR COMPARTMENT LID LATCH
REAR COMPARTMENT LID RELEASE SWITCH
REAR FUSE BLOCK (LEFT SIDE OF TRUNK)
TAN WIRE
TRUNK FUSE 22
TRUNK RELAY 36
WHT WIRE
