Supplemental restraints circuit for Chevrolet Malibu VII (2008-2012)
Supplemental restraints circuit (1 of 3)
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRIVER SEAT BELT PRETENSIONER (BASE OF LEFT "B" PILLAR)
DRIVER SEAT BELT SWITCH (INTEGRAL TO DRIVER'S SEAT BELT BUCKLE ASSEMBLY)
GROUND SERIAL DATA IGNITION 1
GRY WIRE
HIGH CONTROL LOW CONTROL
HOT AT ALL TIMES AIR BAG (BATT) FUSE
HOT W/ RUN/CRANK RELAY ENERGISED AIR BAG (IGN) FUSE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER CENTER CONSOLE)
LEFT INFLATABLE RESTRAINT FRONT END SENSOR (LEFT FRONT OF ENGINE COMPT)
LEFT INFLATABLE RESTRAINT SIDE IMPACT SENSOR (SIS) (IF EQUIPPED) (DRIVER'S DOOR)
LOW REF SIGNAL LOW REF SIGNAL
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER SEAT BELT PRETENSIONER (BASE OF RIGHT "B" PILLAR)
PNK SENS SERIAL DATA CASE GROUND WIRE
PNK WIRE
PPL
PPL/WHT WIRE
RED/WHT WIRE
RIGHT INFLATABLE RESTRAINT FRONT END SENSOR (RIGHT FRONT OF ENGINE COMPT)
SHORTING BAR
SIGNAL
TAN WIRE
TAN/ORG WIRE
TAN/WHT WIRE
VOLTAGE SIGNAL SIGNAL VOLTAGE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Supplemental restraints circuit (2 of 3)
AIR BAG INDICATOR
BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
GRY WIRE
INFLATABLE RESTRAINT I/P MODULE (RIGHT SIDE OF DASH)
INFLATABLE RESTRAINT STEERING WHEEL MODULE (IN STEERING WHEEL)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (TOP OF STEERING
INSTRUMENT PANEL CLUSTER
LOGIC
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
SEAT BELT INDICATOR
SERIAL DATA
SHORTING BAR
SHORTING BAR COLUMN)
SHORTING BAR PPL
STAGE 1
STAGE 2
TAN WIRE
TAN/WHT WIRE
VEHICLE COMMUNICATIONS INTERFACE MODULE (RIGHT SIDE OF DASH)
W/ ONSTAR
W/O ONSTAR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Supplemental restraints circuit (3 of 3)
AIR BAG OFF IND
AIR BAG ON IND
BELT IND
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE)
CASE GROUND
DK BLU WIRE
DK GRN WIRE
GROUND
HOT W/ RUN/CRANK RELAY ENERGIZED
INFLATABLE RESTRAINT I/P MODULE INDICATOR
LOGIC PASS SEAT BELT IND
OFF IND
ON IND.
PASSENGER SEAT
PNK IGN 1 VOLT WIRE
PNK WIRE
PNK/BLK WIRE
PPL
RUN/ CRANK FUSE
SERIAL DATA
