Shift interlock circuit for Chevrolet Malibu VII (2008-2012)
Shift interlock circuit
2.4L (VIN 5) 2.4L (VIN B) 4 SPEED A/T
2.4L (VIN B) 2.4L (VIN 5), 3.6L (VIN 7) 6-SPEED A/T 4-SPEED A/T
2.4L (VIN B) 3.6L (VIN 7)
3.6L (VIN 7), 2.4L (VIN B) 6 SPEED A/T
44 43 33 53 SRL DATA (-) SRL DATA (+)
5 VOLT LOW REFERENCE REFERENCE
A/T SHIFT LOCK CTRL SOLENOID SUPPLY VOLTAGE
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS)
AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL SOLENOID (ON FLOOR SHIFTER)
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE)
BRAKE PEDAL POSITION (BPP) SENSOR (LEFT SIDE OF DASH)
BRAKE PEDAL POSITION SENSOR SIGNAL
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
DK GRN WIRE
DOOR LOCK FUSE
GROUND
GRY WIRE
HOT AT ALL TIMES
IGN LK CTRL SIG PRK/NEUTRAL
INTERIOR LIGHTS FUSE
LOGIC BATTERY
ORG/ WIRE
ORG/BLK WIRE
PARK/NEUTRAL POSITION (PNP) SWITCH (ON AUTOMATIC TRANSMISSION)
TAN WIRE
TAN/BLK WIRE
WHT WIRE
YEL WIRE
