Anti-lock brakes circuit, except hybrid for Chevrolet Malibu VII (2008-2012)

5-VOLT ABS FUSE 15 ABS FUSE 24 ABS IND. B+ IGN 1 VOLT PNK WIRE BATT ABS FUSE 56 BATT POS VOLT HIGH SPD GMLAN SERIAL DATA + HIGH SPD GMLAN SERIAL DATA + BLK WIRE BLK/WHT WIRE BRAKE PRESSURE MODULATOR VALVE (BPMV) BRN WIRE COMPUTER DATA LINES SYSTEM DIAGNOSTIC DK BLU WIRE DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT FRONT STRUT TOWER) GMLAN SERIAL DATA - GMLAN SERIAL DATA + GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) HOT W/ RUN/CRANK RELAY ENERGIZED IGN INSTRUMENT PANEL CLUSTER (IPC) LATERAL SIG LATERAL SIG YAW RATE DIAGNOSTIC STEERING WHEEL POS SIG B LEFT REAR WHEEL SPEED SENSOR (LEFT REAR WHEEL HUB ASSEMBLY) LF WHEEL SPD SENS SIG LF WHEEL SPD SENS LOW REF LOGIC LOW REF LOW SPEED GMLAN LOW SPEED GMLAN SERIAL DATA LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE PPL PUMP MOTOR PUMP MOTOR CONTROL RED/BLK WIRE RED/WHT WIRE RIGHT REAR WHEEL SPEED SENSOR (RIGHT REAR WHEEL HUB ASSEMBLY) SER DATA SERIAL DATA SIG TAN WIRE TAN/BLK WIRE TRACTION OFF BRAKE IND IND VDC IND WHT WIRE YAW RATE SENS SIG LONGITUDINAL SIG STEERING WHEEL POS SIG A YAW SENS SIG YAW, LATERAL ACCELEROMETER SENSOR YEL WIRE YEL/BLK WIRE

3.6L 2.4L (VIN B) 5 VOLT REF BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE) LOGIC BRAKE FLUID BRAKE FLUID LEVEL SWITCH (ON BRAKE MASTER CYLINDER RESERVOIR) BRAKE PEDAL POSITION (BPP) SENSOR (LEFT SIDE OF DASH) BRK POS SENS SIG BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DATA BUS (-) GMLAN SERIAL HIGH SPEED DK GRN WIRE ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT) GMLAN SERIAL DATA BUS + GRY WIRE HIGH SPEED HIGH SPEED GMLAN SERIAL DATA BUS + LEFT FRONT WHEEL SPEED SENSOR (LEFT FRONT WHEEL HUB ASSEMBLY) LOW REF LT BLU WIRE LT GRN WIRE NCA WIRE ORG/BLK WIRE PNK WIRE RIGHT FRONT WHEEL SPEED SENSOR (RIGHT FRONT WHEEL HUB ASSEMBLY) SEN SIG 2 SIG A SIG B SIGNAL LEVEL SENSOR TAN WIRE TAN/BLK WIRE TRAC CTRL SW SIG TRACTION CONTROL SWITCH WHT WIRE YEL WIRE
