Chevrolet Malibu VII (2008-2012) trans pump drv pump ctrl closed sw sig ajar sw sig Wiring diagram

36-VOLT ANTI-THEFT SYSTEM BAS BATT FUSE 51 BAS IGN FUSE 3 BATTERY BLK WIRE BRN WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE DRAIN WIRE EMISSION 2 FUSE 5 ENG/TRAN COOLING FUSE GROUND GRY WIRE GRY/BLK WIRE HI SERIAL BUS - HI SERIAL BUS - HOT AT ALL TIMES HOT W/ RUN/CRANK RELAY ENERGIZED LOGIC LOW REF LT BLU WIRE LT GRN/BLK WIRE MOTOR NCA WIRE ORG/ WIRE PNK PNK WIRE PNK WIRE PNK/BLK WIRE PNK/WHT WIRE POWER DISTRIBUTION SYSTEM PPL PPL PPL REAR FUSE BLOCK (LEFT SIDE OF TRUNK) RED WIRE RED/WHT WIRE SHIELD SIG (1) SIG (2) SIG 1 SIG 2 SIG 3 SIG 4 STARTER GENERATOR (LOWER LEFT FRONT OF ENGINE) STARTER GENERATOR CONTROL MODULE (SGCM) (LEFT FRONT OF ENGINE COMPT) STUD U SHIELD STUD V SHIELD STUD W SHIELD TAN WIRE TAN/BLK WIRE TRANS PUMP DRV PUMP CTRL CLOSED SW SIG AJAR SW SIG TURN ON SIG DRAIN WIRE LOW REF LOOP SIG LOOP SIG DRAIN WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WATER PUMP SPLY WHT WIRE YEL WIRE
