Chevrolet Malibu VII (2008-2012) outside mirror rearview switch Wiring diagram
This page shows the only wiring diagram for the component.outside mirror rearview switch, which is found in the car Chevrolet Malibu VII (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram outside mirror rearview switch (1 of 1)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE)
DEFOGGER SYSTEM
DOWN
DRIVER OUTSIDE REARVIEW MIRROR
GRN WIRE
HOT AT ALL TIMES
LEFT
LEFT RIGHT
LEFT/ RIGHT UP/ DOWN
NCA WIRE
ORG/ WIRE
OUTSIDE MIRROR REARVIEW SWITCH
PASSENGER OUTSIDE REARVIEW MIRROR
POWER MIRRORS FUSE
PPL
RED WIRE
RIGHT
RIGHT OFF
UP DOWN
WHT WIRE
Go to component -> Power mirrors circuit -> OUTSIDE MIRROR REARVIEW SWITCH
