Chevrolet Malibu VII (2008-2012) malfunc- tion indicator lamp wiring diagram

432 2034 ANTI-LOCK BRAKES SYSTEM A/C REFRIGERANT PRESSURE SENSOR (RIGHT REAR OF ENGINE COMPT) ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM DK GRN WIRE DK GRN/WHT WIRE EMISSION 2 FUSE 5 ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT) ENGINE COOLANT TEMPERATURE (ECT) SENSOR (LOWER RIGHT REAR OF ENGINE) ENGINE OIL PRESSURE (EOP) SWITCH (LOWER LEFT REAR OF ENGINE) EVAPORATIVE EMISSION (EVAP) CANISTER PURGE SOLENOID VALVE (TOP, REAR OF ENGINE) FUEL LEVEL SENSOR FUEL PUMP FUEL PUMP FUSE 25 FUEL PUMP/ SENDER ASSEMBLY (IN FUEL TANK) FUEL/ PMP RELAY 37 GMLAN DATA GRY WIRE HOT AT ALL TIMES IGN IGNITION SWITCH INSTRUMENT PANEL CLUSTER (IPC) LEFT "C" PILLAR) LOGIC LOW REF LOW REF LOW REF LT GRN WIRE MALFUNC- TION INDICATOR LAMP MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR (TOP LEFT SIDE OF ENGINE) OFF ORG/BLK WIRE PARK/ NEUTRAL SIG PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PPL REAR FUSE BLOCK (LEFT SIDE OF TRUNK) RED/WHT WIRE RUN WIRE SENS SIG SENS SIG SENS SIG SERIAL BUS+ SOL CTRL RLY CTRL STARTING/ CHARGING SYSTEM SW SIG TAN WIRE TAN/BLK WIRE TRANSMISSIONS SYSTEM YEL WIRE
