Chevrolet Malibu VII (2008-2012) logic pass seat belt ind Wiring diagram
This page shows the only wiring diagram for the component.logic pass seat belt ind, which is found in the car Chevrolet Malibu VII (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram logic pass seat belt ind (1 of 1)
AIR BAG OFF IND
AIR BAG ON IND
BELT IND
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE)
CASE GROUND
DK BLU WIRE
DK GRN WIRE
GROUND
HOT W/ RUN/CRANK RELAY ENERGIZED
INFLATABLE RESTRAINT I/P MODULE INDICATOR
LOGIC PASS SEAT BELT IND
OFF IND
ON IND.
PASSENGER SEAT
PNK IGN 1 VOLT WIRE
PNK WIRE
PNK/BLK WIRE
PPL
RUN/ CRANK FUSE
SERIAL DATA
Go to component -> Supplemental restraints circuit (3 of 3) -> LOGIC PASS SEAT BELT IND
