Chevrolet Malibu VII (2008-2012) left automatic transmission manual shift switch Wiring diagrams
This page contains all the electrical diagrams for the component. left automatic transmission manual shift switch, in which he is found in the car Chevrolet Malibu VII (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left automatic transmission manual shift switch (1 of 2)
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR
AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS)
B+ GROUND
BLK WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
CRUISE CONTROL SYSTEM
GMLAN DATA BUS+ GMLAN DATA BUS+ GMLAN DATA BUS- TAP UP/TAP DN SW STOP LAMP SW
GRN WIRE
IGN
INFLATABLE RESTRAINT STEERING WHEEL
LEFT AUTOMATIC TRANSMISSION MANUAL SHIFT SWITCH
LOW REF
MODULE COIL (TOP OF STEERING WHEEL)
ORG/BLK WIRE
PC 1 SOLENOID
PC 2 SOLENOID
PC 3 SOLENOID
PC 4 SOLENOID
PC 5 SOLENOID
PNK WIRE
PPL
PRESSURE CONTROL (PC) SOLENOID VALVE 1
PRESSURE CONTROL (PC) SOLENOID VALVE 2
PRESSURE CONTROL (PC) SOLENOID VALVE 3
PRESSURE CONTROL (PC) SOLENOID VALVE 4
PRESSURE CONTROL (PC) SOLENOID VALVE 5
RED WIRE
RED/WHT WIRE
RESTRAINT WHEEL MODULE)
SHIFT SOLENOID (SS) VALVE 1
SHIFT SOLENOID (SS) VALVE 2
SS 1
SS 2
TAN WIRE
TAN/BLK WIRE
TCC SOLENOID
TFT
TORQUE CONVERTER CLUTCH (TCC) PRESSURE CONTROL (PC) SOLENOID VALVE
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION RANGE SIG A
TRANSMISSION RANGE SIG B
TRANSMISSION RANGE SIG C
TRANSMISSION RANGE SIG P
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
W/ MANUAL SHIFT CONTROL
WHT WIRE
YEL WIRE
Go to component -> 2.4l vin b, transmission circuit, 6 speed a/t (1 of 2) -> LEFT AUTOMATIC TRANSMISSION MANUAL SHIFT SWITCH
Wiring diagram left automatic transmission manual shift switch (2 of 2)
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION FLUID PRESSURE (TFP) MANUAL VALVE POSITION SWITCH
AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
CRUISE CONTROL SYSTEM
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
GMLAN DATA BUS+ TAP UP/TAP DN SW
GMLAN SERIAL GMLAN SERIAL
GROUND GMLAN DATA BUS+
IGN
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (TOP OF STEERING WHEEL)
INSTRUMENT PANEL CLUSTER (IPC)
LEFT AUTOMATIC TRANSMISSION MANUAL SHIFT SWITCH
LOGIC
LOW REF
PC 1 SOLENOID
PC 2 SOLENOID
PC 3 SOLENOID
PC 4 SOLENOID
PC 5 SOLENOID
PNK WIRE
PPL
PRESSURE CONTROL (PC) SOLENOID VALVE 1
PRESSURE CONTROL (PC) SOLENOID VALVE 2
PRESSURE CONTROL (PC) SOLENOID VALVE 3
PRESSURE CONTROL (PC) SOLENOID VALVE 4
PRESSURE CONTROL (PC) SOLENOID VALVE 5
SHIFT SOLENOID (SS) VALVE 1
SHIFT SOLENOID (SS) VALVE 2
SS 1
SS 2
TAN WIRE
TAN/BLK WIRE
TCC SOLENOID
TFP 1
TFP 3
TFP 4
TFP 5
TFT
TORQUE CONVERTER CLUTCH (TCC) PRESSURE CONTROL (PC) SOLENOID VALVE
TRANSMISSION CONTROL MODULE (TCM)
W/ MANUAL SHIFT CONTROL
Go to component -> 3.6l vin 7, transmission circuit (1 of 2) -> LEFT AUTOMATIC TRANSMISSION MANUAL SHIFT SWITCH
