Chevrolet Malibu VII (2008-2012) gnd logic illum Wiring diagram
This page shows the only wiring diagram for the component.gnd logic illum, which is found in the car Chevrolet Malibu VII (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd logic illum (1 of 1)
1 2 3 4 GROUND HEATED SEAT SW SIG ACCY VOLTAGE BATTERY POSITIVE
1 2 3 4 GROUND HEATED SEAT SW SIG ACCY VOLTAGE BATTERY POSITIVE VOLTAGE
1 2 SEAT BACK ELEMENT CTRL SEAT BACK ELEMENT VOLTAGE
ACCY VLT
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE)
DRIVER BACK HEATED SEAT ELEMENT (DRIVER'S SEAT BACK)
DRIVER CUSHION HEATED SEAT ELEMENT (DRIVER'S SEAT CUSHION)
DRIVER HEATED SEAT CONTROL MODULE (UNDER DRIVER'S SEAT)
DRIVER HEATED SEAT SWITCH
GND ILLUM LOGIC
GND LOGIC ILLUM
GRY WIRE
HEATED SEAT SW SIG
HEATED SEAT SW SIG LOW
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
HTD SEAT FUSE 14
LT BLU/BLK WIRE
PASSENGER BACK HEATED SEAT ELEMENT (FRONT PASSENGER'S SEAT BACK)
PASSENGER CUSHION HEATED SEAT ELEMENT (FRONT PASSENGER'S SEAT CUSHION)
PASSENGER HEATED SEAT CONTROL MODULE (UNDER FRONT PASSENGER'S SEAT)
PASSENGER HEATED SEAT SWITCH
REAR FUSE BLOCK (LEFT SIDE OF TRUNK)
RED WIRE
RED/WHT WIRE
ROOF/ HEAT SEAT FUSE
WHT WIRE
YEL WIRE
Go to component -> Heated seats circuit -> GND LOGIC ILLUM
