Chevrolet Malibu VII (2008-2012) evap sol ctrl gen turn on sig tac motor ctrl 2 cmp intake sens cmp exhaust sens Wiring diagram

BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE CKP SENS SIG 1 INTAKE SENS 1 EXHAUST SENS 1 CRANKSHAFT POSITION (CKP) SENSOR (LOWER LEFT REAR OF ENGINE) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT) ENGINE OIL PRESSURE (EOP) SWITCH (LOWER LEFT REAR OF ENGINE) EVAP SOL CTRL GEN TURN ON SIG TAC MOTOR CTRL 2 CMP INTAKE SENS CMP EXHAUST SENS EXHAUST CAMSHAFT POSITION (CMP) SENSOR (RIGHT REAR OF ENGINE) EXHAUST SOL 1 INTAKE SOL 1 TAC MOTOR CTRL 1 PPL GRY WIRE GRY/WHT WIRE IC 2 CTRL INTAKE CAMSHAFT POSITION (CMP) SENSOR (LEFT REAR OF ENGINE) KNOCK SENSOR (KS) (ABOVE STARTER MOTOR) LOW REF LOW REF 1 LOW REF 1 IC 1 CTRL IC 3 CTRL IC 4 CTRL LOW REF DUTY CYCLE SIG LOW REF KS SIG KS SIG LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE MAP SENS SIG LOW REF ORG/ WIRE ORG/BLK WIRE ORG/WHT WIRE PNK WIRE PNK/BLK WIRE PPL PPL PNK WIRE PPL PPL PPL/WHT WIRE SIG GROUND STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM SUPPLY VOLT SW SIG TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TP SENS 1 SIG ECT SENS SIG TP SENS 2 SIG LOW REF LOW REF WHT WIRE YEL WIRE YEL/BLK WIRE
