Chevrolet Malibu VII (2008-2012) dr ctrl a mode dr ctrl mode dr ctrl 5 volt ref mode dr pos sig low ref Wiring diagram
This page shows the only wiring diagram for the component.dr ctrl a mode dr ctrl mode dr ctrl 5 volt ref mode dr pos sig low ref, which is found in the car Chevrolet Malibu VII (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dr ctrl a mode dr ctrl mode dr ctrl 5 volt ref mode dr pos sig low ref (1 of 1)
3.6L 2.4L (VIN B)
A/C
A/C CLU FUSE 1
A/C CLUTCH RELAY 34
A/C COMPRESSOR CLUTCH (FRONT OF A/C COMPRESSOR)
A/C REQ SIG
A/C REQUEST SWITCH
AMBIENT AIR TEMPERATURE SENSOR (CENTER FRONT OF ENGINE COMPT)
B+ VOLT IGN 3 VOLT
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR RESISTOR (RIGHT SIDE OF DASH)
BLOWER MOTOR SWITCH
BRN WIRE
COOL FAN 1 FUSE 17
COOL FAN 2 FUSE 18
COOL/ FAN 1 RELAY 28
COOL/ FAN 2 RELAY 30
COOL/FAN SER/PAR RELAY 29
DEFOG IND
DEFOG SWITCH
DEFOGGER SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DR CTRL A MODE DR CTRL MODE DR CTRL 5 VOLT REF MODE DR POS SIG LOW REF
FRESH FRESH AIR AIR IND SWITCH
GRY WIRE
HOT AT ALL TIMES
HOT W/ PWR/TRN RELAY ENERGIZED
HVAC CONTROL MODULE (CENTER OF DASH)
LEFT ENGINE COOLING FAN (BEHIND LEFT SIDE OF RADIATOR)
LOGIC
LT BLU WIRE
LT GRN/BLK WIRE
OF ENGINE COMPT)
ORG/ WIRE
PNK/WHT WIRE
RADIATOR)
RECIRCULATION RECIRCULATION IND SWITCH
RED/WHT WIRE
REQUEST IND
RIGHT ENGINE COOLING FAN (BEHIND RIGHT SIDE OF
SUPP VOL
TAN WIRE
TEMPERATURE MODE SWITCH CONTROL SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE
WHT WIRE
YEL WIRE
Go to component -> Manual a/c circuit (1 of 2) -> DR CTRL A MODE DR CTRL MODE DR CTRL 5 VOLT REF MODE DR POS SIG LOW REF
