Chevrolet Malibu VII (2008-2012) data + high spd gmlan data - Wiring diagram
This page shows the only wiring diagram for the component.data + high spd gmlan data -, which is found in the car Chevrolet Malibu VII (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram data + high spd gmlan data - (1 of 1)
2.4L (VIN B)
25 65 8 43 57 37 21 53 380 2700 5514 2500 SENS SIG
A/C CLU FUSE 1
A/C CLUTCH RELAY 34
A/C REQ SIG
A/C REQUEST IND
A/C REQUEST SWITCH
AUTOMATIC A/C
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE)
CLU RLY CTRL
COMPUTER DATA LINES SYSTEM
DATA + HIGH SPD GMLAN DATA -
DK GRN WIRE
DK GRN/WHT WIRE
EXCEPT 2.4L (VIN B)
GRY WIRE
HIGH SPEED GMLAN SERIAL DATA (+)
HOT AT ALL TIMES
HOT W/ PWR/TRN RELAY ENERGIZED
HVAC CONTROL MODULE (CENTER OF DASH)
LOGIC
LOW REF HIGH SPD GMLAN
LOW SPEED GMLAN SERIAL DATA
MANUAL A/C
MODE SWITCH
ORG/BLK WIRE
SERIAL DATA
TAN WIRE
TAN/BLK WIRE
TEMPERATURE CONTROL SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
Go to component -> Compressor circuit -> DATA + HIGH SPD GMLAN DATA -
