Chevrolet Malibu VII (2008-2012) brk pos sens sig lo spd ser data bus lo spd ser data bus Wiring diagram
This page shows the only wiring diagram for the component.brk pos sens sig lo spd ser data bus lo spd ser data bus, which is found in the car Chevrolet Malibu VII (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brk pos sens sig lo spd ser data bus lo spd ser data bus (1 of 1)
59 18 31 37 38 LOW REF
63 47 38 56 DETECTION SIG DETECTION SIG LF TRN SIG VLT RF TRN SIG VLT PPL
65 42 PRK LMP RLY CNTL STPLMP SUPPLY VLT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE)
BRAKE PEDAL POSITION (BPP) SENSOR (LEFT SIDE OF DASH)
BRK POS SENS SIG LO SPD SER DATA BUS LO SPD SER DATA BUS
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
GRY WIRE
HAZARD WARNING SWITCH
HOT AT ALL TIMES
LEFT
LEFT FRONT MARKER LAMP
LEFT PARK/ TURN SIGNAL LAMP LEFT FRONT
LOGIC
LT BLU WIRE
LT BLU/WHT WIRE
MIN MAJ
OFF AUTO
PARK HEAD
PPL
PRK LAMPS FUSE 6
PRK LMP SUPPLY VLT RR LMP SUPPLY VLT LR LMP SUPPLY VLT
PRK LP RELAY 27
REAR FUSE BLOCK (LEFT SIDE OF TRUNK)
REPE- ATER LAMP GND
RIGHT
RIGHT FRONT MARKER LAMP
RIGHT FRONT REPE- ATER LAMP
RIGHT PARK/ TURN SIGNAL GND LAMP
TAN WIRE
TAN/BLK WIRE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> BRK POS SENS SIG LO SPD SER DATA BUS LO SPD SER DATA BUS
