Chevrolet Malibu VII (2008-2012) a/t w/o manual shift a/t w/ manual shift Wiring diagram

1-2 SHIFT SOLENOID (SS) VALVE 13 12 3.6L 2.4L 2-3 SHIFT 4-3 SHIFT SOLENOID SOLENOID (SS) VALVE (SS) VALVE 2.4 (VIN 5) 2.4L (VIN 5), 3.6L 4 SPEED 6 SPEED A/T A/T A/T W/O MANUAL SHIFT A/T W/ MANUAL SHIFT ABS FUSE 15 AIR BAG IGN FUSE AUTOMATIC TRANSMISSION BAS IGN FUSE 3 BLK WIRE BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE) DK GRN WIRE ECM IGN FUSE 16 ELECTRIC POWER STEERING (EPS) MODULE (W/O POWER STEERING) ELECTRONIC BRAKE CONTROL MODULE (EBCM) ENGINE CONTROL MODULE (ECM) EPS FUSE EXCEPT 2.4L (VIN 5) FROM HORN FUSE 8 (DIAGRAM 3 OF 4) GENERATOR BATTERY DISCONNECT CONTROL MODULE GENERATOR PNK BATTERY ASSEMBLY WIRE HEATER COOLANT PUMP IBCM (RUN/CRANK) FUSE 21 INFLATABLE RESTRAINT I/P MODULE INDICATOR INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL LOGIC MAF (3.6L) BAS PMPS (2.4L (VIN 5)) FUSE 5 (2.4L (VIN 5)) (3.6L) MASS AIR FLOW (MAF)/ INTAKE AIR TEMPERATURE (IAT) SENSOR PNK PNK RESTRAINT WHEEL MODULE) PNK WIRE PNK PNK WIRE PNK WIRE PPL RED WIRE RUN/ CRANK FUSE RUN/CRANK RELAY 32 STARTER GENERATOR CONTROL MODULE (SCGM) STARTER GENERATOR CONTROL MODULE (SCGM) COOLANT PUMP PNK WIRE TORQUE CONVERTER CLUTCH (TCC) PULSE WIDTH MODULATION (PWM) SOLENOID VALVE TRANS FUSE 4 TRANSMISSION CONTROL MODULE (TCM) W/ ACCESSORY STEERING WHEEL CONTROL PNK WIRE YEL WIRE
