Chevrolet Malibu VII (2008-2012) 5 66 67 park lp sw sig lr trn sig sw rr trn sig sw Wiring diagram

5 66 67 PARK LP SW SIG LR TRN SIG SW RR TRN SIG SW ABS IND. AIR BAG IND AJAR AJAR (FRONT PASSENGER'S DOOR) BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE) BRAKE FLUID LEVEL SWITCH (ON BRAKE MASTER CYLINDER RESERVOIR) BRAKE IND BRN/WHT WIRE CHARGE IND CHIME COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/WHT WIRE DRIVER DOOR LATCH (DRIVER'S DOOR) DRIVER INFORMATION CENTER (DIC) DISPLAY DRIVER SEAT BELT BUCKLE DRIVER SEAT BELT SWITCH ENGINE COOLANT TEMP IND GROUND DISTRIBUTION GROUND DISTRIBUTION SYSTEM GRY/BLK WIRE HEAD HOT AT ALL TIMES HOT AT ALL TIMES BATT SENSE FUSE 54 IGN SENSOR FUSE IGNITION SWITCH IND INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) INSTRUMENT PANEL CLUSTER (IPC) KEY-IN IGNITION SWITCH LEFT LEFT REAR DOOR LATCH AJAR (LEFT REAR DOOR) LEFT SEAT BELT SW LEFT TURN IND LOGIC LOW ENGINE OIL PRESSURE IND LOW REF LOW SPD GMLAN SERIAL DATA LOW SPD GMLAN SERIAL DATA BUS (-) LOW SPEED GMLAN SERIAL DATA LOW TIRE PRESSURE LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE OFF OFF AUTO PARK OFF/RUN CRANK VOLTAGE PARK BRAKE SWITCH (LEFT KICK PANEL) PASSENGER DOOR LATCH PNK WIRE RADIO RED/WHT WIRE RIGHT RIGHT REAR DOOR LATCH AJAR (RIGHT REAR DOOR) RIGHT TURN IND RUN WIRE SEAT BELT IND SERIAL DATA BUS- SERVICE VEHICLE SOON IND SUPPLEMENTAL RESTRAINTS SYSTEM SYSTEM TAN WIRE TAN/WHT WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE YEL/BLK WIRE
