Chevrolet Malibu VII (2008-2012) 5 6 ls gmlan data ls gmlan data Wiring diagrams
This page contains all the electrical diagrams for the component. 5 6 ls gmlan data ls gmlan data, in which he is found in the car Chevrolet Malibu VII (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 5 6 ls gmlan data ls gmlan data (1 of 2)
1 7 LS GMLAN DATA LS GMLAN DATA
1 9 LS GMLAN DATA LS GMLAN DATA
10 9 LS GMLAN DATA LS GMLAN DATA
2 3 LS GMLAN DATA LS GMLAN DATA
2.4L
2.4L 3.6L
2501 2500 2500 2501 6 SPEED A/T
3.6L
32 2 LS GMLAN DATA LS GMLAN DATA
5 6 LS GMLAN DATA LS GMLAN DATA
5060 5060 AUTOMATIC A/C
53 33 43 44 GMLAN DATA BUS + GMLAN DATA BUS -
6 5 LS GMLAN DATA LS GMLAN DATA
7 8 LS GMLAN DATA LS GMLAN DATA
AUTOMATIC TRANSMISSION
BLK WIRE
BLK/WHT WIRE
CONTROL SOLENOID VALVE ASSEMBLY
DATA LINK CONNECTOR (DLC) (LEFT SIDE OF DASH)
DIGITAL RADIO RECEIVER (UNDER CENTER OF REAR PACKAGE SHELF)
DK GRN WIRE
ELECTRIC POWER STEERING (EPS) MODULE (ON STEERING COLUMN)
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT FRONT STRUT TOWER)
ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT)
HIGH SPEED GMLAN SERIAL DATA BUS +
HOT AT ALL TIMES
HVAC CONTROL MODULE (CENTER OF DASH)
HVAC CTRL (BATT) FUSE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER CENTER CONSOLE)
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LOW LOW
MANUAL A/C
MANUAL AUTOMATIC A/C A/C
POWER DISTRIBUTION SYSTEM
RADIO
RED/WHT WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (UNDER CENTER OF REAR WINDOW SHELF)
TAN WIRE
TAN/BLK WIRE
THEFT DETERRENT MODULE (TDM) (ON IGNITION KEY CYLINDER HOUSING)
TRANSMISSION CONTROL MODULE (TCM) (LOWER LEFT FRONT OF ENGINE COMPT)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (RIGHT SIDE OF DASH)
W/ ONSTAR
W/ ONSTAR W/O ONSTAR
W/ RADIO RECEIVER
W/ W/O ELECTRONIC ELECTRONIC POWER POWER STEERING STEERING
W/O ONSTAR
W/O RADIO RECEIVER
W/O W/ ONSTAR ONSTAR
Go to component -> Computer data lines circuit, except hybrid -> 5 6 LS GMLAN DATA LS GMLAN DATA
Wiring diagram 5 6 ls gmlan data ls gmlan data (2 of 2)
1 7 LS GMLAN DATA LS GMLAN DATA
1 9 LS GMLAN DATA LS GMLAN DATA
10 9 LS GMLAN DATA LS GMLAN DATA
2 3 LS GMLAN DATA LS GMLAN DATA
32 2 LS GMLAN DATA LS GMLAN DATA
5 6 LS GMLAN DATA LS GMLAN DATA
5060 5060 AUTOMATIC A/C
53 33 HS GMLAN DATA BUS + HS GMLAN DATA BUS -
6 5 LS GMLAN DATA LS GMLAN DATA
7 8 LS GMLAN DATA LS GMLAN DATA
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER CENTER CONSOLE) LOGIC
DATA LINK CONNECTOR (DLC) (LEFT SIDE OF DASH)
DIGITAL RADIO RECEIVER (UNDER CENTER OF REAR PACKAGE SHELF)
DK BLU WIRE
DK GRN WIRE
ELECTRIC POWER STEERING MODULE (ON STEERING COLUMN)
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT FRONT STRUT TOWER)
ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT)
GENERATOR BATTERY DISCONNECT CONTROL MODULE (BEHIND REAR SEAT)
GRY WIRE
HIGH LOW
HIGH SPEED GMLAN SERIAL DATA BUS +
HOT AT ALL TIMES
HS GMLAN DATA BUS - HS GMLAN DATA BUS + HS GMLAN DATA BUS + HS GMLAN DATA BUS -
HVAC CONTROL MODULE (CENTER OF DASH)
HVAC CTRL (BATT) FUSE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER CENTER CONSOLE)
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LOW SPEED GMLAN SERIAL DATA
MANUAL A/C
MANUAL AUTOMATIC A/C A/C
POWER DISTRIBUTION SYSTEM
RADIO
RED/WHT WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (UNDER CENTER OF REAR WINDOW SHELF)
STARTER GENERATOR CONTROL MODULE (SGCM) (LEFT FRONT OF ENGINE COMPT)
TAN WIRE
TAN/BLK WIRE
THEFT DETERRENT (TDM) MODULE (ON IGNITION KEY CYLINDER HOUSING)
TRANSMISSION CONTROL MODULE (TCM) (LEFT SIDE OF ENGINE COMPT)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (RIGHT SIDE OF DASH)
W/ ONSTAR
W/ RADIO RECEIVER
W/O ONSTAR
W/O ONSTAR W/ ONSTAR
W/O RADIO RECEIVER
WHT/BLU WIRE
WHT/GRY WIRE
Go to component -> Computer data lines circuit, hybrid -> 5 6 LS GMLAN DATA LS GMLAN DATA
