Power top/sunroof circuit for Chevrolet Malibu VI facelift (2006-2008)
Power top/sunroof circuit
ACCESSORY VOLTAGE
BATTERY POSITIVE VOLTAGE
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER FRONT OF CENTER CONSOLE)
BRN WIRE
CLOSE OPEN
DK BLU WIRE
GROUND
HOT AT ALL TIMES
HOT IN ACC OR RUN
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
RED/WHT WIRE
ROOF/HEAT SEAT FUSE
S/ROOF FUSE 10
SUNROOF CONTROL MODULE (REAR OF SUNROOF)
SUNROOF SWITCH
SUNROOF SWITCH CLOSE SIGNAL
SUNROOF SWITCH LOW REFERENCE
SUNROOF SWITCH OPEN SIGNAL
WIPER/ WASHER SYSTEM
YEL WIRE
