Ground distribution circuit for Chevrolet Malibu VI facelift (2006-2008)

2.2L 3.5L, 3.9L 2.2L 73 73 3.5L, 3.9L 3.5L, 2.2L 3.5L, 3.9L A/C COMPRESSOR CLUTCH A/T AUTOMATIC TRANSMISSION BATTERY BLK WIRE BODY CONTROL MODULE (BCM) BRAKE FLUID LEVEL SWITCH BRAKE LAMP DIAGNOSTIC RESISTOR 46 COOL/FAN SER/PAR RELAY 29 COOLANT LEVEL SWITCH DATA LINK CONNECTOR (DLC) ENGINE CONTROL MODULE (ECM) FRT FOG RELAY 36 WPR 1 RELAY 39 HORN SWITCH IGNITION CONTROL MODULE (ICM) INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL INSTRUMENT PANEL CLUSTER (IPC) INTAKE MANIFOLD TUNING (IMT) VALVE SOLENOID INTERNAL MODE SWITCH (IMS) LEFT STEERING WHEEL CONTROLS RIGHT STEERING WHEEL CONTROLS MANUAL A/C AUTOMATIC A/C MASS AIR FLOW (MAF)/ INTAKE AIR TEMPERATURE (IAT) SENSOR PARK/ NEUTRAL POSITION (PNP) SWITCH POWER STEERING CONTROL MODULE RADIO RELAY 31 RIGHT COOLING FAN RUN/CRANK RELAY 32 THEFT DETERRENT CONTROL MODULE TRANSMISSION CONTROL MODULE (TCM) TURN SIGNAL/ MULTIFUNCTION SWITCH WHT WIRE WINDSHIELD WIPER MOTOR ASSEMBLY WPR 2 RELAY 40

AUTOMATIC A/C BLK WIRE BLOWER MOTOR BLOWER MOTOR CONTROL MODULE BODY CONTROL MODULE (BCM) DATA LINK CONNECTOR (DCL) FUEL PUMP, SENDER ASSEMBLY HAZARD SWITCH HOOD AJAR SWITCH HORN ASSEMBLY I/P DIMMER SWITCH INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR LEFT BACKUP LAMP LEFT FRONT PARK/ TURN SIGNAL LAMP LEFT HEADLAMP HIGH BEAM LEFT HEADLAMP LOW BEAM LEFT REAR DOOR LATCH ASSEMBLY PASSENGER DOOR LATCH ASSEMBLY LEFT TAIL LAMP LEFT TAIL/ STOP/ TURN SIGNAL LAMP MANUAL A/C NCA WIRE PASSENGER DOOR LOCK SWITCH REAR WINDOW DEFOGGER GRID DRIVER DOOR LOCK SWITCH DRIVER DOOR LATCH RIGHT FRONT PARK/ TURN SIGNAL LAMP RIGHT HEADLAMP HIGH BEAM RIGHT HEADLAMP LOW BEAM RIGHT REAR DOOR LATCH ASSEMBLY RIGHT TAIL- LAMP RIGHT BACKUP LAMP RIGHT TAIL/ STOP/ TURN SIGNAL LAMP SEDAN W/ KEYLESS ENTRY W/O INTERMITTENT WIND- SHIELD WASHER FLUID LEVEL SWITCH WIND- SHIELD WASHER FLUID PUMP

BLK WIRE CARGO LAMP SWITCH CENTER HIGH MOUNTED STOP LAMP (CHMSL) DOME/ READING LAMP EXTENDED SEDAN FUEL/PMP RELAY 37 LEFT VANITY MIRROR LAMP LIFTGATE RELEASE SWITCH NCA WIRE PASSENGER COMPARTMENT) R/WDO DEFOG RELAY 26 REAR COMPARTMENT LID LATCH REAR FUSE BLOCK (SEDAN: LEFT REAR QUARTERPANEL) (EXTENDED SEDAN: LEFT REAR OF REAR WINDOW DEFOGGER GRID REAR WINDOW WIPER MODULE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (SEDAN) RIGHT LICENSE LAMP RIGHT VANITY MIRROR LAMP SEDAN SUNROOF CONTROL MODULE W/ IN SIDE SUNSHADE MIRROR W/ INTERMITTENT W/ POWER SLIDING SUNROOF WHT WIRE

2.2L A/T SHIFT LOCK CONTROL ASSEMBLY BLK WIRE BODY CONTROL MODULE (BCM) CIGAR LIGHTER CONSOLE AUXILIARY POWER OUTLET DIGITAL RADIO RECEIVER DRIVER HEATED SEAT CONTROL MODULE PASSENGER HEATED SEAT SWITCH DRIVER HEATED SEAT SWITCH DRIVER OUTSIDE REARVIEW MIRROR DRIVER WINDOW SWITCH DRIVER SEAT ADJUSTER SWITCH DVD PLAYER FRONT AUXILIARY POWER OUTLET GARAGE DOOR OPENER TRANSMITTER IGNITION COIL/ MODULE 1 IGNITION COIL/ MODULE 2 IGNITION COIL/ MODULE 3 IGNITION COIL/ MODULE 4 INFLATABLE RESTRAINT FRONT PASSENGER PRESENCE SYSTEM (PPS) MODULE INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) INSIDE REARVIEW MIRROR NCA WIRE PASSENGER HEATED SEAT CONTROL MODULE OUTSIDE REARVIEW MIRROR SWITCH PASSENGER OUTSIDE REARVIEW MIRROR PASSENGER WINDOW SWITCH REAR COMPART- MENT LID RELEASE INTERIOR SWITCH REAR SEAT AUDIO CONTROLLER REAR WIPER/ WASHER SWITCH S BAND TRACTION CONTROL SWITCH W/ AUTOMATIC ADJUSTABLE FRONT SEAT W/ DVD PLAYER W/ ELECTRIC HEATED REMOTE CONTROL W/ ELECTRONIC TRACTION CONTROL W/ FRONT HEATED SEATS W/ FRONT HEATED SEATS W/ INTERMITTENT W/ MANUAL ADJUSTABLE FRONT SEAT W/ ONSTAR W/ REAR SEAT RADIO CONTROLS W/O ELECTRONIC TRACTION CONTROL WHT WIRE
