Back-up lamps circuit for Chevrolet Malibu VI facelift (2006-2008)
Back-up lamps circuit
2.2L
2.2L, 3.5L
28 27 43 44 HI SPD SER DATA + HI SPD SER DATA -
29 46 TRS RANGE SW SIG A TRS RANGE SW SIG B
3.5L, 3.9L
7 37 SER DATA BUS + SER DATA BUS -
AUTOMATIC TRANSMISSION
BACK-UP LP FUSE 17
BACK-UP LP RELAY 33
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE)
BRN WIRE
BU LMP SUP VLT
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT, FORWARD OF BATTERY)
GROUND DISTRIBUTION SYSTEM
HI SPD SER DATA + HI SPD SER DATA -
HOT AT ALL TIMES
INSIDE REARVIEW MIRROR
INTERNAL MODE SWITCH (IMS)
LEFT BACK-UP LAMP
LEFT TAIL/STOP, TURN SIGNAL LAMP
LT BLU WIRE
LT GRN WIRE
PARK/NEUTRAL POSITION SWITCH (3.5L: ON TOP OF TRANSMISSION)
RED/BLK WIRE
REV LMP RLY CTRL
RIGHT TAIL/STOP, TURN SIGNAL LAMP RIGHT BACK-UP LAMP
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TRANSMISSION CONTROL MODULE (TCM) (LEFT REAR OF ENGINE COMPT, NEAR STRUT TOWER)
WHT WIRE
YEL WIRE
