Electronic power steering circuit for Chevrolet Malibu VI facelift (2006-2008)
Electronic power steering circuit
1 2 3 4 5 6 7 8 SERIAL DATA + SERIAL DATA -
B+ GROUND
BLK WIRE
BODY CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EPS FUSE (BCM) (UNDER FRONT OF CENTER CONSOLE)
EPS FUSE 41
HOT AT ALL TIMES
HOT IN RUN OR START
LOGIC
LT BLU WIRE
PNK IGN 1 VOLT WIRE
PNK WIRE
POSITION
POWER STEERING CONTROL MODULE (LEFT OF STEERING COLUMN)
POWER STEERING MOTOR
PPL
PPL STEER SHAFT TOR SENS SIG 2
RED WIRE
RED/BLK WIRE
RT AST MTR CNTL LT AST MTR CNTL
SERIAL DATA (-) SERIAL DATA (+)
STEER SHAFT TOR SENS SIG 1
STEER WHEEL POS SEN 5 VOLT REF
STEER WHEEL POS SEN LOW REF
STEER WHEEL POS SEN SIG 1
STEER WHEEL POS SEN SIG 2
STEERING COLUMN ASSEMBLY
TAN WIRE
TAN/BLK WIRE
TORQUE
TORQUE/ POSITION SENSOR
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
WHT WIRE
