Chevrolet Malibu VI facelift (2006-2008) right tail/stop, turn signal lamp right back-up lamp Wiring diagram
This page shows the only wiring diagram for the component.right tail/stop, turn signal lamp right back-up lamp, which is found in the car Chevrolet Malibu VI facelift (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right tail/stop, turn signal lamp right back-up lamp (1 of 1)
2.2L
2.2L, 3.5L
28 27 43 44 HI SPD SER DATA + HI SPD SER DATA -
29 46 TRS RANGE SW SIG A TRS RANGE SW SIG B
3.5L, 3.9L
7 37 SER DATA BUS + SER DATA BUS -
AUTOMATIC TRANSMISSION
BACK-UP LP FUSE 17
BACK-UP LP RELAY 33
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE)
BRN WIRE
BU LMP SUP VLT
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT, FORWARD OF BATTERY)
GROUND DISTRIBUTION SYSTEM
HI SPD SER DATA + HI SPD SER DATA -
HOT AT ALL TIMES
INSIDE REARVIEW MIRROR
INTERNAL MODE SWITCH (IMS)
LEFT BACK-UP LAMP
LEFT TAIL/STOP, TURN SIGNAL LAMP
LT BLU WIRE
LT GRN WIRE
PARK/NEUTRAL POSITION SWITCH (3.5L: ON TOP OF TRANSMISSION)
RED/BLK WIRE
REV LMP RLY CTRL
RIGHT TAIL/STOP, TURN SIGNAL LAMP RIGHT BACK-UP LAMP
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TRANSMISSION CONTROL MODULE (TCM) (LEFT REAR OF ENGINE COMPT, NEAR STRUT TOWER)
WHT WIRE
YEL WIRE
Go to component -> Back-up lamps circuit -> RIGHT TAIL/STOP, TURN SIGNAL LAMP RIGHT BACK-UP LAMP
