Chevrolet Malibu VI facelift (2006-2008) a/c req sig low spd gmlan low spd gmlan Wiring diagram

A/C CLU FUSE 1 A/C CLUTCH RELAY 34 A/C COMPRESSOR CLUTCH (LOWER RIGHT FRONT OF ENGINE) A/C REFRIGERANT PRESSURE SENSOR (LEFT OF RIGHT FRONT STRUT TOWER) A/C REQ SIG A/C REQ SIG LOW SPD GMLAN LOW SPD GMLAN A/C REQUEST IND A/C REQUEST SWITCH BLK WIRE BODY CONTROL MODULE (BCM) (UNDER FRONT OF CENTER CONSOLE) COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/WHT WIRE ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT, FORWARD OF BATTERY) EXCEPT 2.2L 2.2L GRY WIRE HIGH SPEED GM LAN SERIAL DATA HOT AT ALL TIMES HOT IN RUN OR START HVAC CONTROL MODULE (CENTER OF DASH) LOGIC LOGIC LOW REF CLU RLY CTRL DATA BUS+ DATA BUS- LOW SPEED GM LAN SERIAL DATA MODE SWITCH ORG/BLK WIRE SENS SIG TAN WIRE TAN/BLK WIRE TEMPERATURE CONTROL UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
