Chevrolet Malibu VI facelift (2006-2008) 2501 2500 1161 1271 1057 computer data lines system Wiring diagrams
This page contains all the electrical diagrams for the component. 2501 2500 1161 1271 1057 computer data lines system, in which he is found in the car Chevrolet Malibu VI facelift (2006-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 2501 2500 1161 1271 1057 computer data lines system (1 of 2)
2501 2500 1161 1271 1057 COMPUTER DATA LINES SYSTEM
335 5069 2759 1310 COOLING FANS SYSTEM
459 3223 3122 AIR CONDITIONING SYSTEM
A/C RELAY CTRL
A/C SENS SIG LOW REF
ACCELERATOR PEDAL POSITION (APP) SENSOR (ATTACHED TO ACCELERATOR PEDAL)
BANK 1 SENSOR 2 (AFTER CATALYTIC) CONVERTER)
BLK WIRE
BLK/WHT WIRE
BRAKE LAMP DIAGNOSTIC RESISTER 46
BRN WIRE
BRN/WHT WIRE
COOLING FANS SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT, FORWARD OF BATTERY)
EVAPORATIVE EMISSION (EVAP) CANISTER VENT SOLENOID VALVE
FAN RELAY CTRL RELAY CTRL LOW REF EVAP VENT CTRL
FUEL RELAY CTRL
FUEL TANK PRESSURE (FTP) SENSOR (UNDER REAR OF VEHICLE)
GROUND
GRY WIRE
GRY/WHT WIRE
HEATED OXYGEN
HOT AT ALL TIMES
IAT SENS SIG
IGN 1 FUSE 3
IGN 1 VOLT SPEED SIG
LAMP SW SIG PPL
LT BLU WIRE
MAF SENS SIG
MIL CTRL PPL
NCA WIRE
ORG/BLK WIRE
ORG/WHT WIRE
PCM FUSE 13
PCM IGN 1 FUSE 16
PNK WIRE
PNK/BLK WIRE
PPL
PPL 1 2 3
PPL LOW REF SENS SIG
PPL SENS SIG FAN RELAY CTRL ACCESSORY VOLT IGN 1 VOLT B+
PPL/WHT WIRE
RED/WHT WIRE
RELAY COIL CTRL
RUN/ CRANK RELAY 32
SER DATA - SER DATA + APP SENS 1 SIG LOW REF LOW REF APP SENS 2 SIG
STARTING/CHARGING SYSTEM
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l vin n (1 of 4) -> 2501 2500 1161 1271 1057 COMPUTER DATA LINES SYSTEM
Wiring diagram 2501 2500 1161 1271 1057 computer data lines system (2 of 2)
11 12 13 14 15 16 17 PNK WIRE
2501 2500 1161 1271 1057 COMPUTER DATA LINES SYSTEM
335 5069 2759 1310 6392 459 3223 3122 COOLING FANS SYSTEM
A/C SENS SIG LOW REF
ACCELERATOR PEDAL POSITION (APP) SENSOR (ATTACHED TO ACCELERATOR PEDAL)
AIR CONDITIONING SYSTEM
AUTOMATIC TRANSMISSION
BANK 1 SENSOR 2 (AFTER CATALYTIC) CONVERTER)
BLK WIRE
BLK/WHT WIRE
BRAKE LAMP DIAGNOSTIC RESISTER 46
BRN WIRE
BRN/WHT WIRE
COOLING FANS SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ECM FUSE 13
ECM IGN 1 FUSE 16
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT, FORWARD OF BATTERY)
EVAPORATIVE EMISSION (EVAP) CANISTER VENT SOLENOID VALVE (ON TOP REAR OF ENGINE)
FAN RELAY CTRL RELAY CTRL LOW REF EVAP VENT CTRL IMT VALVE CTRL A/C RELAY CTRL
FUEL RELAY CTRL
FUEL TANK PRESSURE (FTP) SENSOR (UNDER REAR OF VEHICLE)
GROUND
GRY WIRE
GRY/WHT WIRE
HEATED OXYGEN
HOT AT ALL TIMES
IAT SENS SIG LOW REF SPEED SIG
IGN 1 FUSE 3 IMTV/DOD FUSE 45
IGN 1 VOLT
IMT VALVE SIG
INJ FUSE 5 OR 44
INTERNAL MODE SWITCH (IMS)
LAMP SW SIG
LT BLU WIRE
MAF SENS SIG
MIL CTRL PPL
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/WHT WIRE
PNK WIRE
PNK/BLK WIRE
PPL
PPL 1 2 3
PPL LOW REF SENS SIG
PPL SENS SIG FAN RELAY CTRL ACCESSORY VOLT IGN 1 VOLT B+
PPL/WHT WIRE
RED/WHT WIRE
RELAY COIL CTRL
RUN/ CRANK RELAY 32
SER DATA - SER DATA + APP SENS 1 SIG LOW REF LOW REF APP SENS 2 SIG
STARTING/CHARGING SYSTEM
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TO POST
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 3.9l vin 1 (1 of 4) -> 2501 2500 1161 1271 1057 COMPUTER DATA LINES SYSTEM
