Wiper/washer circuit for Chevrolet Malibu VI (2003-2006)
Wiper/washer circuit
ACCESSORY RELAY
ACCESSORY RELAY CONTROL
BLK WIRE
BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
COMPUTER DATA LINES SYSTEM
DELAY SWITCH
DISPLAY
DK GRN WIRE
FUSE BLOCK UNDERHOOD (ON LEFT SIDE OF ENG COMPT)
GRY WIRE
HOT AT ALL TIMES
LOGIC
LOW SPEED WASHER FLUID
MIST
MIST HIGH
OFF INT
OFF LOW
ORG/ WIRE
PPL
RADIO
TAN/WHT WIRE
WASHER SWITCH
WINDSHIELD WASHER FLUID LEVEL SWITCH (LEFT FRONT WHEELWELL, BOTTOM OF RESERVOIR)
WINDSHIELD WASHER FLUID PUMP (LEFT FRONT WHEELWELL, BOTTOM OF RESERVOIR)
WINDSHIELD WASHER PUMP CONTROL
WINDSHIELD WIPER MOTOR ASSEMBLY (ON LEFT REAR OF ENG COMPT)
WINDSHIELD WIPER MOTOR PARK SWITCH SIGNAL
WINDSHIELD WIPER SWITCH SIGNAL 1
WINDSHIELD WIPER SWITCH SIGNAL 2
WINDSHIELD WIPER/ WASHER SWITCH
WIPER 1 RELAY 39
WIPER 2 RELAY 40
WIPER FUSE 14
WIPER SW FUSE
WIPER SWITCH
YEL WIRE
