Power windows circuit for Chevrolet Malibu VI (2003-2006)
Power windows circuit
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BELOW RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
BRN WIRE
DK DK
DK LT
DK LT PPL
DOWN
DRIVER WINDOW MOTOR
DWN
ECB
EXPRESS
EXPRESS DOWN MODULE
FRONT PASSENGER WINDOW MOTOR
FRONT PASSENGER WINDOW SWITCH
GRN WIRE
GRY WIRE
HOT W/ ACCESSORY RELAY ENERGIZED
ILLUMINATION LAMP
LEFT FRONT
LEFT REAR
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH
LOCK OUT SWITCH
POWER WINDOW SWITCH- DRIVER
POWER WINDOWS FUSE
PPL
PPL DK DK
RIGHT FRONT
RIGHT REAR
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
TAN WIRE
UP DOWN
UP UP
YEL WIRE
