Power top/sunroof circuit for Chevrolet Malibu VI (2003-2006)
Power top/sunroof circuit
BATTERY POSITIVE VOLTAGE
BLK WIRE
BODY CONTROL MODULE (BCM) (BELOW RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
BRN WIRE
CLOSE
DK BLU WIRE
GROUND
HOT AT ALL TIMES
HOT IN ACCY, RUN
LOGIC
ORG/ WIRE
RED/WHT WIRE
ROOF/HEAT SEAT FUSE 10
SUN RF FUSE 10
SUN ROOF SWITCH
SUNROOF CONTROL MODULE (REAR OF SUNROOF)
SUNROOF MOTOR
SUNROOF MOTOR CLOSE SIGNAL
SUNROOF MOTOR OPEN CONTROL SUNROOF MOTOR CLOSE CONTROL
SUNROOF MOTOR OPEN SIGNAL
SUNROOF SWITCH LOW REFERENCE
YEL WIRE
